Home > Products > Electrical Instruments > UT58C LCD Digital Multimeter Max.Display 1999 Tester Meter
UT58C LCD Digital Multimeter Max.Display 1999 Tester Meter
USD $25 - $35
/ Piece
1 Piece(Min.Order)
- 3000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
Acrel AMC16Z-FAK48 Electric Module Multi Channel Current Detection Module For Data Center Precision Cabinet
-
Acrel AMC16Z-FAK48 Electric Muti channel Monitoring Module Data Center Precision Cabinet
-
Acrel AMC16Z-FAK48 Electric Muti Channel Monitoring Module Data Center Precision Cabinet
-
48 Circuit Monitoring Data Center Monitor Power Supply Management Server Multi Loop Energy Meter AMC16Z-FAK48
-
Acrel AMC16Z-FAK48 Electric Muti Channel Monitoring Module Data Center Precision Cabinet
-
Din Rail Ac Power Meter AMC16Z-FAK48 Multi-circuit Energy Meter One RS485 Communication 48 Branch Full Electric Parameter
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | UNI-T | Model Number: | UT58C |
| Measuring Current Range: | 2mA/200mA/20A | Measuring Voltage Range: | AC:2V/20V/200V/750V,DC:200mV/2V/20V/200V/1000V | Measuring Resistance Range: | 200W/2kW/20kW/2MW/20MW |
| Measuring Capacitance Range: | 2nF/200nF/100mF | Dimensions: | 179 x 88 x 39mm |
Product Description
Specifications
UT58C LCD Digital Multimeter Max.Display 1999 Tester Meter
UT58C LCD Digital Multimeter Max.Display 1999 Tester Meter
SPECIFICATIONS
| Basic Functions | Range | Best Accuracy |
|---|---|---|
| DC Voltage | 200mV/2V/20V/200V/1000V | (0.5%+1) |
| AC Voltage | 2V/20V/200V/750V | (0.8%+3) |
| DC Current | 2mA/200mA/20A | (0.8%+1) |
| AC Current | 2mA/200mA/20A | (1%+3) |
| Resistance | 200W/2kW/20kW/2MW/20MW | (0.8%+1) |
| Capacitance | 2nF/200nF/100mF | (4%+3) |
| Temperature(°C) | -40°C ~ 1000°C | (1%+3) |
| Frequency | 2kHz/20kHz | (1.5%+5) |
| Special Functions | ||
| Diode | ||
| Continuity Buzzer | ||
| Transistor | ||
| Data Hold | ||
| Full Icon Display | ||
| Sleep Mode | ||
| Low Battery Display | ||
| Input Impedance for DC Voltage Measurement | Around 10MW | |
| Max Display | 1999 |
GENERAL CHARACTERISTICS
| Power | 9V Battery (6F22) |
| LCD Size | 60 x 54mm |
| Product Colour | Grey Holster - Red |
| Product Net Weight | 350g (including holster) |
| Product Size | 179 x 88 x 39mm |
| Standard Accessories | Test Lead, Battery, English Manual, Point Contact Temperature Probe, Multi-Purpose Socket, Holster |
| Standard Individual Packing | Gift Box |
| Standard Quantity Per Carton | 40pcs |
| Standard Carton Measurement | 598 x 418 x 340mm (0.085 CBM Per Standard Carton) |
| Standard Carton Gross Weight | 27kg |
Edited by ZACK
