Specifications
MASTECH MY60 series Handheld Digital Multimeter
MASTECH MY60 series Handheld Digital Multimeter
Environment conditions:
1000V CAT. II and 600V CAT. III
Pollution degree: 2
Altitude < 2000m
Operating temperature:
0~40 °c, 32°F~122°F (<80% RH, <10 °c non-condensing)
Storage temperature:
-10~60 °c, 14°F ~140°F (<70% RH, battery removed)
* Temperature Coefficient:
0.1×(specified accuracy) /(<18 °c or >28 °c)
* MAX. Voltage between terminals and earth ground:
750V AC rms or 1000V DC.
* Fuse Protection:
μA and mA: F 500mA/250V ø5×20;
10A: F 10A/250V ø6.3×32.
* Sample Rate: 3 times/sec for digital data.
* Display:
3 3/4 digits LCD display. Automatic indication of functions and symbols.
* Range selection: automatic and manual.
* Over Range indication: LCD will display "OL".
* Low battery indication:
The "" is displayed when the battery is under the proper operation range.
* Polarity indication: "−" displayed automatically.
* Power source: 9V
* Battery type: NEDA 1604, 6F22, or 006P.
* Dimensions: 91(L)×189(W)×31.5(H) mm.
* Weight: 310g. Approx. (battery included).
|
|
|
