Autorange Digital Multimeter MASTECH MS8221C

Specifications

Autorange Digital Multimeter MASTECH MS8221C

Main features:

Compliance with international safety standards IEC1010-1 CAT ΙΙΙ 600V.

Second injection

Automatic range

Data Hold

Maximum measurement

Background light

Automatic shutdown

Display: 1999 counts, digit height 16mm

DC: 200m/2/20/200/600V ± 0.7%

AC voltage: 200m/2/20/200/600V ± 0.8%

DC current: 200μ/2000μ/20m/200mA ± 1.2%, 2/10A ± 2.0%

AC Current: 200μ/2000μ/20m/200mA ± 1.5%, 2/10A ± 3.0%

DC current (with clamp measurements, the first clamp reprovision): 200A/2000A (0.1mV/0.1A) ± 1.2%

AC Current (with clamp measurements, the first clamp reprovision): 200A/2000A (0.1mV/0.1A) ± 1.5%

Resistance: 200/2K/20K/200K/2MΩ ± 1.2%; 20MΩ ± 2.0%

Temperature: -20 ºC - 1000  ºC ± 3.0%, 0 ºF- 1800 ºF ± 3.0%

Capacitance measurement: 20n/200n/2μ/20μ/200μ/2000μF ± 4.0%

Continuity Test

Diode test

Transistor hFE Test

Power supply: 1.5V (AAA) × 3

Dimensions: 158 × 74 × 31mm

Weight: about 220g (including battery)
