High Precision Mastech MS8221 Autorange Multimeter With Temperature Test
High Precision Mastech MS8221 Autorange Multimeter With Temperature Test
Main features:
Designed to international safety standard IEC 1010-1 CAT III 600V
Secondary injection molding case
Auto range
Data hold
Maximum value measurement
Back light
Auto power off
Display: 1999 counts, digit is 16mm high
DC voltage: 200m/2/20/200/600V0.7%
AC voltage: 200m/2/20/200/600V0.8%
DC current: 200/2000/20m/200mA1.2%, 2/10A2.0%
AC current: 200/2000/20m/200mA1.5%, 2/10A3.0%
DC current (with clamp, optional): 200/2000A(0.1mV/0.1A)1.2%
AC current (with clamp, optional): 200/2000A(0.1mV/0.1A)1.5%
Resistance: 200/2k/20k/200k/2M1.2%, 20M2.0%
Temperature: -20C ~ 1000C3.0%, 0F ~ 1800F3.0%
Battery test: 1.5V (test current approx. 60mA)
3V (test current approx. 30mA)
9V (test current approx. 12mA)
Continuity test
Diode test
Transistor hFE test
Power: 1.5V (AAA) x 3
Size: 158mm x 74mm x 31mm
Weight: Approx. 220g
