Help CenterKyoritsu 3021 Digital Insulation / Continuity Tester 125V/250V/500V/1000V
Related Products
-
Brand New KYORITSU 3007A Digital Insulation / Continuity Tester 250V/500V/1000VUS$ 400 - 434MOQ: 1 Piece -
NEW Kyoritsu Insulation Continuity Tester 3005A DIGITAL DISPLAY 250V/500V/1000VUS$ 334 - 367MOQ: 1 Piece
-
Rigol DM3068 6 1/2 Digit Digital MultimeterUS$ 1,160 - 1,500MOQ: 1 Piece
-
Bench Digital Multimeter RIGOL DM3068US$ 1,200 - 1,500MOQ: 1 Piece
-
UNI-T UT151A Digital Multimeter AC/DC Resistance Capacitance Frequency OhmUS$ 25 - 50MOQ: 1 Piece
Since it's founding in 1940, Kyoritsu has made customer satisfaction and providing high quality products and services our top priorities. Our emphasis on customer support has helped us to build strong and lasting customer and distributor relationships that continue today.
Storeinfinity recommends reputable Digital Insulation/ Continuity Tester brands such as Kyoritsu meters for their outstanding performance and system features make it a perfect solution for your reliable testing requirement, fast and safe delivery, best quality with irresistible Price.
Features:
- 3 functions in one unit, insulation test with 4 voltage ranges, continuity test, AC voltage measurement
- 200mA measuring current on continuity testing
- Comparator function with PASS / FAIL and buzzer
- 0Ω adjustment at continuity measuring range
- Memory function up to 99 data
- Backlight LCD provides easy reading in dark locations
- Safety lock system prevents an erroneous operation on 500 and 1000 Volt ranges
- Safety standard IEC 61010-01 CAT.III 600V
Insulation resistance | ||||
Test voltage |
125V |
250V |
500V |
1000V |
Measuring range |
4.000/40.00/ |
4.000/40.00/400.0/2000MΩ |
||
First Effective Measuring range |
0.1~20MΩ |
0.1~40MΩ |
0.1~200MΩ |
0.1~1000MΩ |
Mid-scale value |
5MΩ |
50MΩ |
||
Accuracy |
±2%rdg±6dgt |
|||
Second effective measuring range lower |
0~0.099MΩ |
|||
Second effective measuring range upper |
20.01~200.0MΩ |
40.01~2000MΩ |
200.1~2000MΩ |
1001~2000MΩ |
Accuracy |
±5%rdg±6dgt |
|||
Rated current |
DC 1~1.2mA |
|||
Output short circuit current |
1.5mA max |
|||
Ω/Continuity | ||||
Auto range |
40.00/400.0Ω |
|||
Accuracy |
±2%rdg±8dgt |
|||
Output Voltage on open circuit |
5V±20% |
|||
Output short circuit current |
DC 220±20mA |
|||
Fuse |
Quick acting ceramic fuse 0.5A/600V (Ø6.35×32mm) |
|||
AC Voltage | ||||
Range |
AC 20~600V (50/60Hz) |
|||
Accuracy |
±3%rdg±6dgt |
|||
General | ||||
Applicable standards |
IEC 61010-1 CAT.III 600V, IEC 61557-1,2,4, IEC 61326-1 (EMC), IEC 60529 (IP40) |
|||
Dimensions / Weight |
105(L) × 158(W) × 70(D)mm / 600g approx. |
|||
Power source |
R6P×6 or LR6×6 |
|||
Edited by Sam
