Home > Instruments & Meters > Electronic Instrument > Clamp Meter > UNI-T UT206 Digital Clamp Multimeters,digital Meter,multimeter Digital
UNI-T UT206 Digital Clamp Multimeters,digital Meter,multimeter Digital
US$ 45 - 80
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT206
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
NEW PROVA-19 Digital Harmonics and Leakage Tester Meter V/A True RMSUS$ 321 - 356MOQ: 1 Piece -
Three-phase Intelligent Power Clamp Meter YH351US$ 190 - 200MOQ: 1 Piece
-
ACM01 Portable Digital AC Clamp Meter Backlight Datahold Auto PowerUS$ 19 - 25MOQ: 1 Piece
-
New ACM03 Auto Range Digital Clamp Meter Multimeter AC DC Current Voltage Hz Frequency Capacitance TesterUS$ 30 - 40MOQ: 1 Piece
-
2014 New ACM04 True RMS Digital AC DC Current Voltage Clamp Meter Multimeter Capacitance Frequency Inrush Current TestUS$ 45 - 50MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT206
Display Type
Digital Only
Measuring Current Range
AC:400A/1000A
Measuring Voltage Range
AC:4V/40V/400V/600V,DC:400mV/4V/40V/400V/600V
Measuring Resistance Range
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ
Measuring Capacitance Range
40nF/400nF/4mF/40mF/200mF
Dimensions
260*104*52mm
Weight
530g
Specifications
UNI-T UT206 Digital Clamp Multimeters,digital meter,multimeter digitalUNI-T UT206 Digital Clamp Multimeters,digital meter,multimeter digital
pecifications
Basic functions |
Range |
Basic accuracy |
DC Voltage |
400mV/4V/40V/400V/600V |
±(0.8%+1) |
AC Voltage |
4V/40V/400V/600V |
±(1.2%+5) |
AC Current |
400A/1000A |
±(1%+5) |
Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ |
±(1%+2) |
Capacitance |
40nF/400nF/4mF/40mF/200mF |
±(3%+5) |
Frequency |
10Hz-10MHz |
±(0.1%+3) |
Special functions | ||
Relative mode |
√ |
|
Diode |
√ |
|
Duty cycle |
√ |
|
Continuity buzzer |
√ |
|
Sleep mode |
√ |
|
Low power indication |
√ |
|
Input impedance |
10MΩ |
√ |
Data hold |
√ |
|
Auto range |
√ |
|
backlight |
√ |
|
Jaw light |
√ |
|
Maximum display |
3999 |
|
Jaw open |
40mm |
|
GENERAL CHARACTERISTICS
Power |
9V battery (6F22) |
LCD display |
52*27mm |
Product color |
Red + Grey |
Product weight |
530g |
Product size |
260*104*52mm |
Standard accessories |
Test Lead, English manual, battery, tool box |
Edited by ZACK
