NEW PROVA-19 Digital Harmonics and Leakage Tester Meter V/A True RMS
NEW PROVA-19 Digital Harmonics and Leakage Tester Meter V/A True RMS
Specifications
*Non-interrupted Harmonic Analysis
*Programmable CT Ratio (1 to 250)
*Harmonic Analysis (V and A) to the 99th Order
Feature:
1.True RMS value (V and A)
2.Leakage Current Measurement at 10 μ A Resolution
3.Harmonic Analysis (V and A) to the 99 th Order
4.Better Understanding of High Frequency Harmonic Analysis (up to 5/6 KHz)
5.Non-interrupted Harmonic Analysis
6.Analysis of Total Harmonic Distortion (THD-F)
7.Analysis of Crest Factor (C.F.)
8.Fast Peak Function (33 μs and 39 μs)
9.Programmable CT Ratio (1 to 250)
Specification :
AC Current (50 or 60 Hz, True RMS)
Range |
Resolution |
Accuracy of Readings |
0.30 – 60.00mA |
0.01mA |
±0.5% ± 5dgts |
60.0 – 600.0mA |
0.1mA |
±0.5% ± 5dgts |
0.030 – 3.000 A |
0.001 A |
±0.5% ± 5dgts |
3.00 – 30.00 A |
0.01 A |
±0.5% ± 5dgts |
30.00 – 50.00 A |
0.01 A |
±1.0% ± 5dgts |
Harmonics of AC Voltage in % and Magnitude (1 to 99th order)
Range |
Resolution |
Accuracy in % |
Resolution |
Accuracy in Magnitude |
50V – 600V |
0.1 % |
±0.5% |
0.1 V |
±0.5% ± 0.5V |
General Specification
| Conductor Size | 30mm (approx.) |
| Battery Type | 1.5V SUM-3 x 2 |
| Display | 4+2+2 digits LCD |
| Power Consumption | 5mA (approx.) |
| Auto-Power-Off | 30 minutes |
| No. Of Samples/Period | 512 (V & A), 256 (W) |
| LCD update rate | 2 times / sec. |
| Weight | 200g (battery included) |
| Operating Temperature | -10 ° C to 50° C |
| Operating Humidity | < 85% relative |
| Storage Temperature | -20° C to 60° C |
| Storage Humidity | < 75% relative |
| Dimension | 210 (L) x 62 (W) x 35.6mm (H), 8.3" (L) x 2.5" (W) x 1.4" (H) |
| Accessories | test leads, Carrying bag x 1, Users manual x 1, Batteries 1.5V x 2 |
| Option | alligator clips |
