2014 New ACM04 True RMS Digital AC DC Current Voltage Clamp Meter Multimeter Capacitance Frequency Inrush Current Test
US$ 45 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Graigar
Model Number:
ACM04
Display Type:
Analog and Digital
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MASTECH Mini Digital Clamp Leaker MS2007B High Sensitive MeterUS$ 140 - 160MOQ: 1 Piece -
Voltmeter Ammeter Multimeter Digital Clamp Meter MS2008CUS$ 27 - 35MOQ: 1 Piece
-
MS2026R 3-Phase Power Multimeter Digital Clamp MeterUS$ 50 - 60MOQ: 1 Piece
-
MS2138R Digital AC DC Current Clamp Meter True RMS Multimeter Voltage Capacitance Resistance TesterUS$ 58 - 70MOQ: 1 Piece
-
MS2007B Clamp Meter AC Current Leak Measurement Tool High Sensitive Clamp MeterUS$ 62 - 72MOQ: 1 Piece
Brand Name
Graigar
Model Number
ACM04
Display Type
Analog and Digital
Measuring Current Range
66A/600A
Measuring Voltage Range
660mV/6.6V/66V/600V
Measuring Resistance Range
660Ω/6.6kΩ/66kΩ/660kΩ/6.6MΩ±1.0%, 66MΩ ±2.0%
Measuring Capacitance Range
6.6uF/66uF/660uF/6.6mF/66mF±4.0%
Operating Temperature
0° C to 40° C(32° F to 104° F)
Dimensions
208mm*7mm8*35mm
Weight
245g
Specifications
2014 New ACM04 True RMS Digital AC DC Current Voltage Clamp Meter Multimeter Capacitance Frequency Inrush Current Test
Product Description
2014 New ACM04 True RMS Digital AC DC Current Voltage Clamp Meter Multimeter Capacitance Frequency Inrush Current Test
This meter is a portable professional measuring instrument with LCD and back light easily reading. The ‘single-hand operation’ design for the range switch makes measurement simple and easy. Overload protection and low battery indication are provided. It is an ideal multi-function Instrument with scores of practical applications for professional, workshop, school, hobby and home use.
Features
According to IEC-1010 , CAT III 600V and pollution 2
Auto range and manual range
Measure AC/DC voltage and current, resistance, frequency, duty, capacitance, as well as continuity and diode test
True RMS (at AC A and AC V range)
Inrush current measurement
Auto zero function (at DCA range)
Measure frequency by clamp
Reading hold
Maximum value/minimum value
Auto power off
Back light
Clamp Lighting
Specifications
Overrange protection is provided for all ranges.
Maximum voltage between terminals and earth ground: 600V DC or rms AC
Operating altitude: max. 2000 meters (7000 ft.)
Display: LCD
Maximum value display: 6599 digits
Polarity indication: automatic; "-"for negative polarity.
Overrange indication: ‘0L’ or ‘-0L’
Sampling Time: approx. 0.4 second per sample
Unit indication: function and unit.
Auto power off time: 30 min.
Operating power : 1.5Vx3 AAA batteries (not include)
Size: 208mm x 78mm x 35 mm
Battery low indication
Temperature factor: < 0.1xAccuracy /° C
Operating temperature: 0° C to 40° C(32° F to 104° F)
Storage temperature: -10° C to 50° C(10° F to 122° F)
