UNI-T UT200A LCD Digital Clamp Multimeter Ohm DMM DC AC Voltmeter AC Ammeter

Specifications

UNI-T UT200A LCD Digital Clamp Multimeter Ohm DMM DC AC Voltmeter AC Ammeter

UNI-T UT200A LCD Digital Clamp Multimeter Ohm DMM DC AC Voltmeter AC Ammeter

Features :

UT200A is a stable, secure, and reliable 3 1/2 Digital Clamp Meter.

Full mechanical and electrical circuit design LSI double integral A / D converter change as the core

full scale overload protection circuit, independent.

The special design makes it the superior performance of the dedicated electric Instrumentation.

Clamp can be used to measure AC and DC voltage, AC Current, resistance, diode, the circuit off and so on.



Specifications:
	Range	Accuracy
DC Voltage	600V	±(1.5%+5)
AC Voltage Sine Wave RMS	600V	± (1.0%+3) 40Hz ~ 400Hz
AC Amphere Sine Wave RMS	2A/20A/200A	±(1.5%+5) 50Hz ~ 60Hz
Resistance	20k	± (1.0%+4)



Special Functions:
Flow:	Manual
Diode:	Yes
Continuity Buzzer:	Yes
Data Hold:	Yes
Display Backlight:	White
Power Mode:	Switch On / Off
Low Battery Display:	7.5V
Input Impedance:	10M
Max Display:	1999
Polarity:	Auto
Speed Test:	2~3 Times / Second
Clamping Size:	28mm
Conductor Size:	Diameter 26mm Max

Edited by ZACK
