Specifications
Mastech MS2115A Digital Clamp Multimeter Meter Frequency Resistance Capacitance Meters Tester
Mastech MS2115A Digital Clamp Multimeter Meter Frequency Resistance Capacitance Meters Tester
|
Specification |
Range |
Accuracy |
|
|
|
MS2115A |
MS2115B |
DC Voltage |
60mV/600mV/6V/60V/600V |
+-(0.7% +3) |
|
600mV/6.6V/66V/660V |
|
+-(0.5% +3) |
|
1000V |
+-(0.8% +2) |
+-(0.8% +2) |
|
AC Voltage |
60mV/600mV/6V/60V/600V |
+-(0.8% +3) |
|
600mV/6.6V/66V/660V |
|
+-(0.8% +3) |
|
750V |
+-(1% +4) |
+-(1% +4) |
|
DC Current |
60A/600A/1000A |
+-(2.5% +6) |
|
66A/660A/1000A |
|
+-3.0% +3) |
|
AC Current |
60A/600A/1000A |
+-(2.5% +6) |
|
66A/660A/1000A |
|
+-(2.5% +3) |
|
Resistance |
600ohm/6kohm/60kohm/600kohm/6Mohm |
+-(0.8% +3) |
|
60Mohm |
+-(1.2% +3) |
|
|
660ohm/6.6kohm/66kohm/660kohm/6.6Mohm |
|
+-(1.0% +3) |
|
66Mohm |
|
+-(1.5% +3) |
|
Capacitance |
10nF/100nF/1000nF/10uF/100uF/1000uF/10mF/100mF |
+-(4.0% +5) |
|
6.6nF/66nF/660nF/6.6µF/66µF/660µF/6.6mF/66mF |
|
+-(4.0% +3) |
|
Frequency (From Clamp) |
0- 10KHz |
+-(1.5% +5) |
+-(1.5% +5) |
Logic Frequency |
0-60MHz |
+-(0.5% +3) |
|
0-66MHz |
|
+-(0.5% +3) |
|
Duty Cycle |
10%- 90% |
+-3.0% |
+-3.0% |
Feature | |||
Display |
counts |
6000 |
6600 |
Jaw Opening |
|
40mm/1.6 |
40mm/1.6 |
Auto Ranging |
|
Yes |
Yes |
Manual Ranging |
|
Yes |
Yes |
Auto Power Off |
|
Yes |
Yes |
REL |
Relative measurement |
Yes |
Yes |
Diode |
2.7V |
Yes |
Yes |
Continuity Buzzer |
<50ohm |
Yes |
Yes |
MAX/MIN |
|
Yes |
Yes |
Data Hold |
|
Yes |
Yes |
Display Backlight |
|
Yes |
Yes |
Low Battery Display |
|
Yes |
Yes |
Flash Light |
|
Yes |
Yes |
|
True RMS |
True root mean square measurement |
Yes |
Yes |
|
NCV |
Non-contact voltage detector |
Yes |
Yes |
|
Inrush |
Inrush current measurement |
Yes |
Yes |
USB interface |
Windows OS |
|
Yes |
General | |||
Power Supply |
1x9V 6F22 Battery |
Yes |
Yes |
Product Size |
mm |
238x92x50 |
238x92x50 |
inch |
9.3x3.6x2.0 |
9.3x3.6x2.0 |
|
Product Weight |
|
400g |
400g |
|
0.9lb |
0.9lb |
|
Category |
CAT.III1000V CAT.IV600V |
CE |
CE |
