Specifications
MASTECH MS2203 3-phase Digital Power Clamp Meter With RS232 cable
MASTECH MS2203 3-phase Digital Power Clamp Meter With RS232 cable
FEATURES:
Power measurement of 3-phase 3-wire, 3-phase 4-wire, single-phase mode
V, A, W, VA, VAR, kWh, PF, Hz measurement
Double display two parameters on each menu and store 28 groups of measurement parameter
Measure total power value and five power parameters of each phase in 3-phase measurement mode respectively
Autorange and TRMS display
With PC RS232 interface and windows graphics software
Display measurement time and select tested signal be power supply for the clamp at one time, the instrument can measurement for long time
Large LCD display, multifunctional button contro
| Special Function | |||
| Model | MS2203 | ||
| Max conductor size | ?50mm | ||
| AC Current(A) | 40/100/400/1000A ±2% | ||
| AC Voltage(V) |
|
||
| Active Power(kW) | 4/10/40/100/600kW ±3.0% |
||
| Apparent Power(kVA) | 4/10/40/100/600kVA±3.0% |
||
| Power Factor(PF) | 0.3cap to 0.3ind ±0.02 | ||
| Reactive Power(KVAR) | 4/10/40/100/600kVAR ±4.0% |
||
| Active Energy(kWh) | 10/100/1000/10000kWh ±3.0% | ||
| Frequency(Hz) | 20Hz~1000Hz 0.5% | ||
| Display | 4 digits LCD 9999 | ||
| Power supply | 4 x 1.5V AA | ||
| OperatingTemperture | 0°C~ 40°C |
||
| Dimension | 300mm x 103mm x 51mm | ||
| Weight | 500g | ||
Packing list:
1x 3-Phase Digital Power Factor Clamp Meter
4x Color banana test leads for 4 wire testing
4x Alligator clips
1x Hardcase
1x RS232 cable
1x English manual and software CD
