Digital Clamp Meter/Uni-Trend/UT231/Digital 3 PHASE Power Clamp Meters UT231 TESTER METERDigital Clamp Meter/Uni-Trend/UT231/Digital 3 PHASE Power Clamp Meters UT231 TESTER METER
SPECIFICATIONS
Basic Functions |
Range |
Best Accuracy |
AC Voltage |
15V/100V/300V/600V |
(1.2%+5) |
AC Current |
40A/100A/400A/1000A |
(2%+5) |
Active Power |
0.01kW-600kW |
(3%+5) |
Apparent Power |
0.01kVA-600kVA |
(3%+5) |
Reactive Power |
0.01kVAr-600kVAr |
(4%+5) |
Power Factor |
0.3~1(Capacitive or Inductive ) |
(0.02+2) |
Phase Angle |
0o~360O |
1O |
Frequency |
20Hz-500Hz |
√ |
Active Energy |
1~9999 kWh |
(3%+2) |
Temperature |
-50OC~1300OC |
3OC |
Special Functions |
|
|
Auto Ranging |
|
√ |
Single-phase 2-wire |
|
√ |
3-phase 3-wire |
|
|
3-phase 4-wire |
|
|
True RMS |
AC Voltage or Curren |
√ |
Calibration Feature |
|
√ |
Data Logging |
99 |
√ |
Data Recall |
|
√ |
Max/Min Mode |
|
√ |
Data Hold |
|
√ |
USB |
|
√ |
Display Backlight |
EL |
√ |
Full Icon Display |
|
√ |
Sleep Mode |
|
√ |
Low Battery Display |
|
√ |
|
Input Impedance for AC Voltage Measurement |
Around 10MW |
√ |
Max. Display |
9999 |
√ |
Analogue Bar Graph |
|
√ |
GENERAL CHARACTERISTICS
Power |
1.5V Battery (LR6) x 4 |
LCD Size |
46 mm x 42 mm |
Product Color |
Red and Grey |
Product Net Weight |
601g |
Product Size |
303 x 112 x 39 mm |
Standard Accessories |
UT231 - Test Lead, Batteries, English Manual, Point |
Standard Individual Packing |
Gift Box |
Standard Quantity Per Carton |
24 pcs |
Standard Carton Measurement |
610 x 360 x 305 mm (0.067 CBM Per Standard Carton) |
Standard Carton Gross Weight |
28kg |
