B35T OWON DM Series Digital Multimeter Datalogger+multimeter + Temperature Meter Function as 3 in 1,support via Smart Power-off

B35T OWON DM Series Digital Multimeter Datalogger+multimeter + Temperature Meter Function as 3 in 1,support via Smart Power-off thumbnail-3

B35T OWON DM Series Digital Multimeter Datalogger+multimeter + Temperature Meter Function as 3 in 1,support via Smart Power-off thumbnail-4

B35T OWON DM Series Digital Multimeter Datalogger+multimeter + Temperature Meter Function as 3 in 1,support via Smart Power-off photo-1

B35T OWON DM Series Digital Multimeter Datalogger+multimeter + Temperature Meter Function as 3 in 1,support via Smart Power-off photo-2

B35T OWON DM Series Digital Multimeter Datalogger+multimeter + Temperature Meter Function as 3 in 1,support via Smart Power-off photo-3

B35T OWON DM Series Digital Multimeter Datalogger+multimeter + Temperature Meter Function as 3 in 1,support via Smart Power-off photo-4

US$ 40 - 48 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

B35T OWON DM Series Digital Multimeter datalogger+multimeter + temperature meter function as 3 in 1,support via smart power-off

OWON DM Series Digital Multimeter
Product Series : DM Series

Main Features

- function as 3 in 1 : datalogger + multimeter + temperature meter
- multi-connection (more than one device) supported via mobile app
- the change trend analysis accessible via special chart mode
- voice warning supported, which assures measurement safety
- smart voice-reading accessible
- 3(5/6)-digit full scale reading, achieving higher measurement accuracy than 3(3/4)-digit counterparts
- larger display, easier data-reading; simulated bar chart comes as an added option
- backlit-powered screen, more suitable for dark measurement environment
- smart power-off option extending battery life
- true RMS value available (only in B35T, and D35T)

Application

electronic circuit debugging circuit testing
design and manufacture education and training
automobile maintenance and testing

		Measurement Range	Resolution	Accruacy
DC Voltage	mV	60.00mV/600.0mV	0.01mV	±(0.5%+2dig)
	V	60.00mV/600.0mV/6.000V/60.00V	0.1mV
	V	600.0V/1000V	0.1V
AC Voltage	mV	60.00mV/600.0mV	0.01mV	±(0.8%+2dig)
	V	60.00mV/600.0mV/6.000V/60.00V	1mV	±(0.8%+2dig)
	V	600.0V/750V	0.1V	±(1%+3dig)
DC Current	μA	600.0μA	0.1μA	±(0.8%+2dig)
	mA	600.0μA/6.000mA/60.00mA/600.0mA/6.000A	0.01mA	±(0.8%+2dig)
	A	20.00A	1mA	±(1.2%+3dig)
AC Current	μA	600.0μA	0.1μA	±(1%+3dig)
	mA	600.0μA/6.000mA/60.00mA/600.0mA/6.000A	0.01mA	±(0.8%+2dig)
	A	20.00A	1mA	±(2%+3dig)
Resistance		600.0Ω/6.000kΩ/60.00kΩ/600.0kΩ/6.000MΩ/10.00MΩ	0.1Ω	±(0.8%+2dig)
Resistance		60.00MΩ	0.01MΩ	±(2%+3dig)
Capacitance		40.00nF	0.01nF	±(2.5%+3dig)
		400.0nF/4.000μF/40.00μF	0.1nF	±(2.5%+3dig)
		400.0μF/4000μF	0.1μF	±(3%+5dig)
Frequency		9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/ 9.999MHz	1mHz	±(0.8%+2dig)
Duty Ratio		0.1%~99.9%typical value: Vrms=1V, f=1kHz	0.1%	±(1.2%+3dig)
Duty Ratio		0.1% ~99.9%≥1kHz	0.1%	±(2.5%+2dig)
Temperature		-50~+400	1°C	±(2.5%+3dig)
Temperature		-58°F~+752°F	1°F	±(4.5%+5dig)
Display		6000 count
Frequency		(40-400)Hz
Shift Rate on DMM		3 times / s
Shift Rate on App		2 times / s
Simulated Chart Shift Rate on DMM		30 times / s

Model: D35, D35T, B35, B35T

Bluetooth Module	√ (only in B35, and B35T)	Max / Min Value	√
Auto-scale	√	LCD Backlight	√
True RMS	√ (only in B35T, and D35T)	Simulated Chart	√
Diode Test	√	Input Protection	√
Audion Test	√	Input Impedance	10MΩ
Auto Power-off	√	LCD Size	69 x 52 mm
On-off Warning	√	Display Area	67 x 46 mm(effective area 66 x 45 mm)
Low-battery Indicator	√	Battery	3V (2.5V x 2)
Data Hold	√	Weight (without package)	0.32 kg
Relative Measurement	√
