Home > Instruments & Meters > Meter for Electricity > Multimeter > Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester

Name: Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester
Brand: UNI-T
SKU: 130763579
Availability: InStock

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester thumbnail-1

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester thumbnail-2

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester thumbnail-3

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester thumbnail-4

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester thumbnail-5

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester thumbnail-6

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester photo-1

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester photo-2

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester photo-3

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester photo-4

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester photo-5

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester photo-6

US$ 18 - 23 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

UNI-T

Model Number:

UT54

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name UNI-T

Model Number UT54

Measuring Current Range 20mA/200mA/2mA/20mA/200mA/2A/10A

Measuring Voltage Range 200mV/2V/20V/200V/1000V

Measuring Resistance Range 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ

Measuring Capacitance Range 2nF/20nF/200nF/2μF/20μF

Measuring Inductance Range none

Operating Temperature -20℃~1000℃

Dimensions 190mm*88mm*34mm

Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter Multitester

Contrast

Specifications	Range	Best Accuracy
Model		UT54	UT55
DC Voltage (V)	200mV/2V/20V/200V/1000V	±(0.5%+1)	±(0.5%+1)
DC Current (A)	2mA/20mA/200mA/20A	±(0.8%+1)	±(0.8%+1)
AC Voltage (V)	2V/20V/200V/750V	±(0.8%+3)	±(0.8%+3)
AC Current (A)	20mA/200mA/20A	±(1%+3)	±(1%+3)
Resistance (Ω)	200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ	±(0.8%+1)	±(0.8%+1)
Capacitance (F)	2nF/20nF/200nF/2μF/20μF	±(4%+3)	±(4%+3)
Frequency (Hz)	2kHz/20kHz	±(1.5%+5)	±(1.5%+5)
Frequency (Hz)	20kHz		±(1.5%+5)
Temperature (°C)	-20-1000		±(1%+3)
Features
Transistor		√	√
Diode		√	√
Continuity Buzzer		√	√
Sleep Mode		√	√
Low Battery Display		√	√
Input Impedance for DC Voltage Measurement	10MΩ	√	√
Max. Display	1999	√	√
General Characteristic
Power	9V Battery (6F22)
LCD Size	65mm×33mm
Product Colour	Red and Grey
Product Net Weight	580g (including holster)
Product Size	190mm×88mm×34mm
Standard Accessories	UT54-Test Lead, Battery, Holster
Standard Accessories	UT55-Test Lead, Battery, Holster,Point type temperature probe
Standard Packing	Gift Box, English Manual
Standard Quantity Per Carton	20 Pcs
Standard Carton Measurement	535mm×362mm×385mm
Standard Carton Gross Weight	UT54-20.5kg,UT55-17.4kg
Optional Accessories*	Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2)
