2500V Digital Insulation Resistance Meter Tester Megohmmeter Highly Voltmeter Continuity Tester W/LCD Backlight UNI-T UT502A
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
UNI-T UT70C LCD Digital Multi-purpose Meter Multimeters Volt Amp Ohm Capacitance Tester UT-70C
-
Multifunctions Insulation Resistance Testers UNI-T UT529A Digital Earth Tester 125V/250V/500V Voltage Frequency Tester
-
Bench Type Digital Multimeters UNI-T UT805A Automatic Range True Valid Values Average Value Display
-
UT107 Handheld Automotive Multi-Purpose Meters Ac/dc Voltage Current Tester Multimeter
-
UTE1010B Digital Power Meter True Rms Power Factor Analyzer 3000W Power Quality Analyzer
-
Digital Clamp Earth Ground Resistance Testers UNI-T UT275 0.01-1000ohm Leakage Current Auto Range
Product Details
| Place of Origin | Guangdong, China | Brand Name | UNI-T | |
| Model Number | UT502A | Display Type | Digital Only | |
| Measuring Range | 0.00Mohm-20.0Gohm | Testing Voltage | 500V/1000V/2500V | |
| Operating Temperature | 0℃~40℃ | Dimensions | 150*100*71mm |
Product Description
Features:
DAR: √
PI: √
Auto Range: √
Low Battery Indication: √
LCD Backlight: √
Alarm Light Display: √
Alarm Buzzer: √
High Voltage Indication: √
Over Load Indication: √
Auto Disharge: √
Test Voltage Vice Display: √
Specifications:
Model: UT502A
Insulation Resistance(?): Test Voltage: 500V/1000V/2500V 0%~10%
500V: 0.00M?~99.9M? ±(3%+5) ; 100M?~5.5G? ±(5%+5)
1000V: 0.00M?~99.9M? ±(3%+5) ; 100M?~5.5G? ±(5%+5)
2500V: 0.00M?~99.9M? ±(3%+5) ; 100M?~9.9G? ±(5%+5) ; 10.0G??20.0G? ±(10%+5)
Load Current: 500V(R=500K?) 1mA 0%~10% ; 1000V(R=1M?) 1mA 0%~10% ; 2500V(R=2.5M?) 1mA 0%~10%
Short Circuit Current: <2mA
CONTINUITY(?): Test Voltages: about 5.0V ±(2%+3) ; 0.01?~200? ±(2%+3); Max Current: >200mA
AC Voltage (V): 30V~750V ±(2%+3)
General Characteristic:
Power: 6 * 1.5V Alkaline Batteries (not included)
LCD Size: 65mm x 27mm
Product Net Weight: 500 g
Product Size: 150mm * 100mm * 71mm
Product Color: Red and Grey
Package Size: 18.5 * 15 * 9cm / 7.3 * 5.9 * 3.7in
Package Weight: 757g / 1.7lb
Package List:
1 * UNI-T UT502A Insulation Resistance Meter
1 * Pair Test Lead
1 * Pair Alligator Clips
1 * Carrying Bag
1 * English Manual
