Summary of Blow moulding machine for baby feeding bottle:
PP blow molding machine is widely used in producing feeding bottles, heat resisting bottles, packageing of beverage, cosmetic, food, pharmaceutics, and pesticide etc..
PP single-cavity automatic blow molding machine is designed with international advanced technology, and made up with mechanical, electrical and pneumatic system. The electrical and pneumatic components, sealing element, bearing, speed reducer and other important parts are imported from Europe, America and Japan's top brand products to ensure that the machines are of high quality, good stability and long lifespan. The machine has the advantages of automation, intelligence, stability, high efficiency, low cost etc...
Preform Material:PP
Output:1800bph.
Advantages of Blow moulding machine for baby feeding bottle:
- Use of hydro-pneumatic linkage mold clamping mechanism which runs stably with high speed and great clamping force..
- The control system adopts man-machine interface with Mitsubishi PLC which is easily operated with high sensitivity and accuracy...
- Use of coated infrared heating which helps fast and stable heating..
- Use of centralized noise-reducing air recycling system which helps fast release of exhausted air with little noise.
- Use of slide core in stepping unit which is easy to operate and saves energy..
-The finifhed pp bottle can endure high temperatures up to 85-120 degrees Celsius
Characteristic:
1. High stability, automatic linear bottle blowing machine high stability from the high standards of design and strict processing requirements, but also from the high standard of electricity, gas configuration.
2. The price of excellence, quality products, low prices
3. The special design of the lamp and light box, so that value-blowing machine of HENGGANG more than 30% year on year savings in energy consumption.
4, The main electrical and pneumatic components are imported from Europe, America, Japan and other countries well-known brands of accessories, stable and reliable mechanical operation.
5. The value of HENGGANG machinery, especially for difficult shaped bottle blowing.
6. Machinery automation, simple operation, selection of workers to solve business requirements
Machine Technical Parameters of Blow moulding machine for baby feeding bottle:
Item |
HGA.C-2C |
|
|
Container |
Max. Container Volume |
700 ml |
Neck Diameter Range |
18-38 mm |
|
Max. Container Diameter |
68 mm |
|
Max. Container Height |
240 mm |
|
Theoretical Output |
1800 bph |
|
|
Molding |
Clamping stroke |
100 mm |
Stretching stroke |
240 mm |
|
Bottom Stoke |
50 mm |
|
Preform distance |
76 mm |
|
Preform Holder |
160 pcs |
|
Cavities |
4 No. |
|
Electrical System |
Max. Heating Power |
96 kw |
Heating Power |
35 kw |
|
|
Air System |
Operating Pressure |
7 kg/c m2 |
Low Air Consumption |
1500 ltr/min |
|
Blowing Pressure |
35 kg/c m2 |
|
High Air consumption |
1800 ltr/min |
|
|
Cooling Water |
Operating Pressure |
5-6 kg/c m2 |
Temperature |
8-12°C |
|
Flow rate |
30 ltr/min |
|
Machine |
Size(L×W×H) |
5450×2200×2100 mm |
Weight |
6500 kg |
|
Machine Picture of Blow moulding machine for baby feeding bottle:
Product made by Blow moulding machine for baby feeding bottle:
Our Blow moulding machine for baby feeding bottle has already accquired the CE certificate:
Other domestic patents of our Blow moulding machine for baby feeding bottle:
