Detailed Product Description of PP bottles blowing machinery:
PP blow molding machine is widely used in producing feeding bottles, heat resisting bottles, packageing of beverage, cosmetic, food, pharmaceutics, and pesticide etc.
Preform material:PP
Output:900BPH(750ml)
Features of PP bottles blowing machinery:
1.Using hydro-pneumatic linkage mold clamping mechanism which runs stably with high speed and great clamping force.
2.The control system adopts man-machine interface with Mitsubishi PLC which is of high sensitivity and accuracy.
3.Using coated infrared heating lamps which enable fast and stable heating.
4.Using centralized noise-reducing air recycling system which minimize the noise as much as possible.
5.Using slide core in stepping unit which is easy to operate and saves energy.
Parameters of PP bottles blowing machinery:
Item | HGA.P-2C | |
Container | Max. Container Volume | 750 ml |
Neck Diameter Range | 50 mm | |
Max. ContainerDiameter | 100 mm | |
Max. Container Height | 280 mm | |
Theoretical Output | 900 bph | |
Molding | Clamping stroke | 150 mm |
Stretching stroke | 350 mm | |
Bottom Stoke | 25 mm | |
Preform distance | 130 mm | |
Preform Holder | 62 pcs | |
Cavities | 2 No. | |
Electrical System | Max. Heating Power | 48 kw |
Heating Power | 20 kw | |
Air System | Operating Pressure | 7 kg/c m2 |
Low Air Consumption | 1500 ltr/min | |
Blowing Pressure | 35 kg/c m2 | |
High Air consumption | 1000 ltr/min | |
Cooling Water | Operating Pressure | 5-6 kg/c m2 |
Temperature | 8-10°C | |
Flow rate | 30 ltr/min | |
Machine | Size(L×W×H) | 3100×1750×1750mm |
Weight | 2800 kg | |
The pictures of PP bottles blowing machinery:
Product pictures:
Our factory
All the cavity molds(moulds) are manufactured by ourselves. We have our own CNC processing machine and experienced engineer, who has been making cavity molds at least 5 years. Besides the cavity molds, other hardware parts are also produced by ourselves. Thus we have strong confidence in the stability of our machine because all parts can jointed and worked as a integrated unit.
The most frequently used material for molds are Aluminum, S136(stainless iron):
Our engineer is making the technical drawing by the software UG:
Our PP bottles blowing machinery has already accquired the CE certificate:
The business target of Henggang is to build up a company which provides the most cost effective and most comprehensive services in packaging machines. With professional skill and every effort, we are concentrating on every detail in manufacturing packaging machines, from the product design, parts processing, electrical components configuration, and quality control in production processes to the aftersales services, dedicated to making excellent devices for you. Henggang upholds its management philosophy of innovation, professionalism and enthusiasm as well as a sincere co-operative attitude in order to achieve win-win business opportunity with our customers.
