Digital Weighing System

Name: Digital Weighing System
Brand: Manyyear
SKU: 130662937
Availability: InStock

US$ 50 - 70 MOQ: 1 Piece

Key Specifications

Brand Name:

Manyyear

Model Number:

ADS102

Power:

Other, AD

Manyyear Technology Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Brand Name Manyyear

Model Number ADS102

Power Other, AD

Usage Compression Testing Machine

Product Description

ADS102 digital weight system

Features

1.voltage: 6.5V~12V DC
2.power protect, voltage protect, peak protect.
3.Digital filter
4.digital demarcate:
5.characteristic parameter store
6.sample rate option
7.set all item by series port
8.zero track range:±2%
9.zero adjust range when power on ±2%~±20%
10.linearity correct point option(4~8)
11.temperature correct, adjust time can be option
12.short response time of measure
13.Prevent vibrate Intension option 0%~100%
14. update by series port

Technology

1.Max signal range:	±15mV
2 MAX resolving power :	±1500k/±15mV(12.5Hz)
3.Measure speed:	100Hz,50Hz,25Hz,12.5Hz,6.25Hz,3.125Hz, 2Hz,1Hz(option)
4.Filter mode:	standard low-filter and FIR filter
5.Nor-linearity:	±0.001%F·S
6.Temperature characteristic:	<±5ppm/ºC
7.Communication mode:	RS232/RS485/MODBUS/WIRELESS
8.baud rate:	1200,2400,4800,9600,19200bps (option)
9.Power supply:	6.5V~12V DC
10.Current:	< 38 mA < 40mA Max
11.Work temperature range:	-40ºC~+70ºC
12.Stock temperature range:	,-60ºC~+90ºC
13. AD-S dimension(mm):	Diameter: 32mm,thickness: 8mm
