Vertical Balancing Machine for Brake Disc, Impeller, Flywheel
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
TC
Model Number:
YLD
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fan Balancing Machine YYW-1600ANegotiableMOQ: 1 Set -
Balancing Machine YYW-5000ANegotiableMOQ: 1 Set
-
Hard Bearing Armature Dynamic Balancing Machine YYQ-1600ANegotiableMOQ: 1 Set
-
Balancing Machine, Fan Impeller Balancing YYW-1000ANegotiableMOQ: 1 Set
-
Balancing Machine, Rotor Fan Balancing YYW-1000ANegotiableMOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
TC
Model Number
YLD
Warranty period:Life-time warranty. Any problem caused by our party within one year from the date of shipment, we will provide free spare parts for the repairment. After one year, we can provide the spare parts, but the user should pay for the related cost, including cost of the spare parts, delivery cost etc.
Technical Data:
Model |
Workpiece weight (Kg ) |
Workpiece diameter (mm) |
Balancing rotation speed (r/min) |
Min.achievable residual unbalance (Gmm/kg) |
Unbalance reduction Ratio (%) |
Motor power (kw) |
Adjusting speed form |
YLD-5 |
0.1-5 |
500 |
250-2500 |
≤ 3 |
≥90 |
0.37 |
Frequency control motor |
YLD-16 |
0.5-16 |
500 |
250-2500 |
≤ 3 |
≥90 |
0.85 |
|
YLD-42 |
3-42 |
800 |
250-2500 |
≤ 3 |
≥90 |
1.5 |
|
YLD-100 |
5-100 |
800 |
250-2500 |
≤ 3 |
≥90 |
4 |
|
YLD-200 |
10-200 |
800 |
250-2500 |
≤ 3 |
≥90 |
4 |
Photos:
Testing interface:
