Help CenterBalancing Machine for Rotor Fan, Fan Impeller YYQ-50A
Related Products
-
Balancing Machine for Centrifugal Impeller, Turbine Rotor YYQ-50ANegotiableMOQ: 1 Set -
Hard Bearing Armature Dynamic Balancing Machine YYQ-50ANegotiableMOQ: 1 Set
-
Hard Backing Armature Dynamic Balancing Machine YYQ-50ANegotiableMOQ: 1 Set
-
Belt Drive Dynamic Centrifugal Pump Balancing Machine YYQ-100ANegotiableMOQ: 1 Set
-
Rotor Balancing Machine, Dynamic Balancing YYQ-160ANegotiableMOQ: 1 Set
Specifications
balancing machinerotor fan balancing machine
fan impeller balancing machine
computer display
CE certified
Features:
1.The industrial computer employs Windows XP operating system, steady and easy to operate
2.Introducing excellent quality sensors with high sensitivity, as small as 0.001g
3.Real-time displaying amount of unbalance, phase and rotation speed
4.Efficient
5.Large data storage, can store more than 100 sets of balancing results
6.belt drive hard bearing horizontal balancing machine
Widely used in electric motors, fan/blower, diesel engine, farm machine, textile machiner, printing machine, paper-making machine, water pump, automoible etc
Warranty period:
Life-time warranty. Any problem caused by our party within one year from the date of shipment, we will provide free spare parts for the repairment. After one year, we can provide the spare parts, but the user should pay for the related cost, including cost of the spare parts, delivery cost etc.
Technical Data:
Model |
Weight of workpiece (kg) |
Max.diameter of workpiece (mm) |
Distance between two support bearings(mm) |
Range of Journal Diameter (mm) |
Balancing speed (rpm) |
Min. achievable residual unbalance (g.mm/kg): |
Unbalance reduction ratio(%): |
Drive power (kw) |
YYQ-50A |
1-50 |
900 |
60-800 |
8-70 |
300-5000 |
<=0.5 |
>=90 |
0.75 |
