Foldable and Portabe High Efficiency Solar Panels

US$ 0.45 - 1.2 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Model Number:

GH141

Zhejiang Ganghang Solar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GH

Model Number GH141

Material Monocrystalline Silicon

Size 1580*808*40mm

Number of Cells 72

Max. Power 185watt

Foldable solar panels

MONO or POLY	Mono
Maximum power (Wp)	185wp
Maximum power voltage (V)	36.42
Maximum power current (A)	5.09
Open circuit voltage (V)	45.26
Short circuit current (A)	5.43
Number of cells (Pcs)	72
Size of module (mm)	158080840mm( 125x125mm cell)
Maximum system voltage (V)	1000
Temperature coefficients of Isc (%)	+ 0.1/
Temperature coefficients of Voc (%)	-0.38/
Temperature coefficients of Pm (%)	-0.47/
Temperature coefficients of Im (%)	+0.1/
Temperature coefficients of Vm (%)	-0.38/
Temperature Range	-40~+80
Tolerance Wattage (e.g. +/-5%)	+/-5%
Surface Maximum Load Capacity	60m/s(200kg/sq.m)
Allowable Hail Load	256g steel ball fall down from 1m height
Weight per piece (kg)	16
Junction Box Type	PV-RH0301( TUV )
Connectors and Cables Type
Length of Cables (mm)	900mm
Cell Efficiency (%)	16.8%
Module Efficiency (%)	14.49%
Output tolerance (%)	+/-5%
Frame (Material, Corners, etc.)	Aluminum
Backing (Brand, type)
Standard Test Conditions	AM1.5 100mW/cm2 25C
Warranty	2 years product warranty and 25 years 80% of power
FF (%)	73%
Packing	2PCS/CTN ,600PCS/300CTN/40 FCL
Packing Dimension	1630855140mm
