Specifications
solar panelCertifications: CE, IEC, TUV UL
MOQ:1PCS
Competitive price :0.75-0.95usd/w
25 years warranty
High efficiency monocrystalline silicon solar panel
· Module Efficiency: 14.3%
· Perfect for high-power grid-tie and high-power battery charging
using a MPPT charge controller.
· High transparent low-iron, tempered glass
· Unique techniques give the panel the following features: aesthetic appearance,
high wind-pressure and snow load tolerance, and easy installation
· Unique technology ensures that water freezing and warping do not occur
· Designed to meet the unique demands of customers
· 25 year transferable power output warranty: 10 years warranty, 90% power output
25 years warranty, 80% power output
· Class C fire rating
2.Electrical Data and Module Dimension
STC:Irrandiance 1000w/m2,Module temperature 25°C,AM=1.5
3.Temperature Ratings
Nominal Operating cell temperature (NOCT):46°C (±2°C)
Temperature Coefficient of PMPP-0.45%/°C
Temperature Coefficient of VOC:-0.35%/°C
Temperature Coefficient of ISC:0.05%/°C
4.Maximum Ratings
Operating Temperature: -40 ~ +85°C
Storage Temperature: -40 ~ +85°C
Maximum System Voltage: 1000VDC
Maximum Series Fuse: 30A
| Pmax(W) |
Model |
Voc(V) | Isc(A) | Vmp(V) | Imp(A) | Module dimension L×W×H(mm) |
Array of Cell |
| 150 | GH-150 | 44.48 | 4.59 | 36.00 | 4.17 | 1580*808*35 | 6×12(72pcs) |
| 155 | GH-155 | 44.48 | 4.74 | 36.00 | 4.31 | 1580*808*35 | 6×12(72pcs) |
| 160 | GH-160 | 41.80 | 5.07 | 34.50 | 4.64 | 1580*808*35 | 6×12(72pcs) |
| 165 | GH-165 | 43.60 | 5.08 | 35.40 | 4.66 | 1580*808*35 | 6×12(72pcs) |
| 170 | GH170 | 44.20 | 5.15 | 35.00 | 4.78 | 1580*808*35 | 6×12(72pcs) |
| 175 | GH-175 | 44.20 | 5.25 | 35.80 | 4.89 | 1580*808*35 | 6×12(72pcs) |
| 180 | GH-180 | 44.20 | 5.36 | 36.20 | 4.97 | 1580*808*35 | 6×12(72pcs) |
| 185 | GH-185 | 44.90 | 5.52 | 36.20 | 5.11 | 1580*808*35 | 6×12(72pcs) |
| 190 | GH-190 | 45.70 | 5.53 | 36.60 | 5.19 | 1580*808*35 | 6×12(72pcs) |
| 195 | GH-195 | 45.80 | 5.59 | 37.10 | 5.26 | 1580*808*35 | 6×12(72pcs) |
