Specifications
Solar module/solar panel1.Solar panel:255W
2.Certification:TUV IEC CE
3.Monocystalline Silicon
4.MOQ:1000 PCS
Solar modules/Panel
Our products have got the certificates of IEC, TUV, UL, CE, PV CYCLE membership and etc.
|
Parameters type
|
GH-089 |
Mono-crystalline silicon | |
Maximum power (watt) W |
255W |
Production tolerance |
+3% /-3% |
Maximum power voltage V |
48.6±0.5V |
Maximum power current A |
5.25A |
Open circuit voltag V |
59.5V |
Short circuit current A |
5.45A |
Size of module (wide and high) |
1580*1060*45(MM) |
Number of cells |
96PCS |
Size of cells(wide and high) |
125mm*125mm ,mono cell |
Weight per piece KG |
24KGS |
Certificates |
CE, ISO9001 ,TUV,MCS |
|
Cable type and length, connector type |
4 TUV certified cable 1m long Multi contact connector (compatible to MC type IV) |
Temperature coefficient of Isc |
±0.05%°C |
Temperature coefficient of Voc |
-0.33%°C |
Temperature coefficient of power |
-0.23%°C |
Temperature coefficient of Imp |
+0.08%°C |
Temperature coefficient of Vm |
-0.33%°C |
NOCT(nominal operating cell temperature) |
45°C(±°C) |
Insulation |
100MOhm |
Voltage standoff |
AC2000V, DC 3000V |
Wind bearing |
60m/s(200kg/sq.m) |
Impact resistance hail impact test |
227g steel ball fall down from 1m height |
Encapsulated with toughened glass |
Low iron tempered glass with thickness of 3.2mm,light transmittance above91% |
Superstrate in front |
Hi-sheet RC 02B (0.45mm thick)/Japan |
Backside foil |
PTL3-38/75(0.17mm thick),Krempel/Germany,0.17mm |
Conversion efficiency |
Cell conversion efficiency16.8% |
Quality guarantee |
5years product warranty,10years 90% and 20yesr 85% of the power |
Price |
FOB Ningbo/Shanghai |
Delivery Time |
20 days after placing the order |
Payment |
T/T or L/C |
