pv Modules Solar Panel Wholesale
US$ 0.49 - 0.7
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GH SOLAR
Model Number:
GHP-280
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI or NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Triangle Solar Modules 280W GH EnergyUS$ 0.49 - 0.62MOQ: 1000 Pieces -
190w Mono Free Shipping Solar PanelUS$ 0.5 - 0.76MOQ: 1000 Pieces
-
Paneles Solares Precio 1000wUS$ 0.57 - 0.72MOQ: 1000 Pieces
-
Solar Panel Manufacturer Solar Modules 40W for Home Use GH EnergyUS$ 0.57 - 0.59MOQ: 1000 Pieces
-
Solar Panel Manufacturer Solar Modules 130W for Home Use GH EnergyUS$ 0.57 - 0.59MOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
GH SOLAR
Model Number
GHP-280
Material
Polycrystalline Silicon
Size
1950*992*50MM
Number of Cells
72pcs
Max. Power
280W
Specifications
1.10 years 90% rated power output2.20 years 80% rated power output
3.CE,IEC,TUV,ULCertificates
4.25 years quality warranty
About GH Solar
Our company has produced solar panel for many years, with reliable quality and very competitive price; we have exported products to many countries. And we also have the office and warehouse in Pakistan (Karachi, Lahore and Islamabad), our company also prepare to open the India office and warehouse.i think this year will be finished.
Welcome to visit our website: ; , any interests, pls feel free to contact with me, i will be happy to service with you.
| Company | Zhejiang Ganghang Solar Technology CO.,LTD |
| Address | No.658,Jianguo North Road,Hangzhou,Zhejiang,China P.C.:310004 |
| Website | |
| Contact person | Jessie |
| Fax | 86-0571-85273827 |
| Tel | 86-0571-88135952 |
| Skype | jessie.ghsolar |
* 1. ELELTRICAL CHARACTERISTICS: | |||||||
| Pmax(Power)* | 280W | ||||||
| Vmpp(nominal voltage) | 35.9V | ||||||
| Impp(nominal current) | 5.15 | ||||||
| Voc(voltage open circuit) | 44.28 | ||||||
| Isc(short-circuit current) | 5.6 | ||||||
| Maximum voltage | 1000V | ||||||
| Cell yield | 14.50% | ||||||
| Power tolerance | 0 to +3% | ||||||
| Thermal coefficients | Voc | -(2.23+/-0.1) mv/deg | |||||
| Isc | 0.065+/-0.015%/deg | ||||||
| Pmax | -(0.5+/-0.05) %/deg | ||||||
| * 2. NOCT: | 45deg | ||||||
| Operating temperature | -45 +80Deg | ||||||
| *STC: Irradiation 1000 W/m2, AM 1.5, Temoerature 25deg | |||||||
| Cell | monocrystalline silicon | ||||||
| Dimensions | 156*156mm | ||||||
| Quantity/arrangment | 72/12x6 | ||||||
| Fram | Anodised aluminium profile | ||||||
| Case/by-pass diodes | IP65/3 | ||||||
| Length of Cables/connector | 900mm | ||||||
| * 3. PHYSICAL CHARACTERISTICS: | |||||||
| Module | RDM-1850M | ||||||
| Dimension(lxhxd) in mm | 1580X808X40 | ||||||
| Weight | 19KG | ||||||
| * 4. One 20' FCL could load: 364pcs, 40' HQ could load: 728 pcs 2pcs in one carton | |||||||
