Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Cell > Hangzhou Advanced Solar Technology 240 Watt Solar Panel

Hangzhou Advanced Solar Technology 240 Watt Solar Panel

Name: Hangzhou Advanced Solar Technology 240 Watt Solar Panel
Brand: GH SOLAR
SKU: 130617759
Availability: InStock

Hangzhou Advanced Solar Technology 240 Watt Solar Panel thumbnail-1

Hangzhou Advanced Solar Technology 240 Watt Solar Panel photo-1

US$ 0.5 - 0.78 MOQ: 1000 Watts

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

GH SOLAR

Model Number:

GHP-240

Contact Supplier Request Quote Chat Now

Zhejiang Ganghang Solar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name GH SOLAR

Model Number GHP-240

Material Polycrystalline Silicon

Size 1650*990*35mm

Number of Cells 60pcs

Max. Power 240W

About GH Solar

Our company has produced solar panel for many years, with reliable quality and very competitive price; we have exported products to many countries. And we also have the office and warehouse in Pakistan (Karachi, Lahore and Islamabad), our company also prepare to open other country office and warehouse.

Welcome to visit our website: ; , any interests, pls feel free to contact with me, i will be happy to service with you.

Company	Zhejiang Ganghang Solar Technology CO.,LTD
Address	Hangzhou,Zhejiang,China P.C.:310004
Website
Contact person	cathy

Feature and Advantage

1. High Efficiency Mono 125*125mm & 156*156mm and Poly 156*156mm.

2. High Efficiency solar cells in series.

3. High Transmissivity low iron toughened glass.

4. High wind-pressure and snow load.

5. Waterproof and ultraviolet resistance junction box.

6. 10 years 90% rated power output, 20 years 80% rated power output

7. 25 years quality warranty

8. high efficiency 1W-320W PV solar panel

Application

1. Solar power stations

2. Rural electrification

3. Small home power systems

4. Designing professional standard PV model for different industry

5. Large on and off-grid solar power stations

6. Commercial/industrial building roof-top systems

7. Residential roof-top systems

8. Other industrial and commercial applications

Specification of module
Model	TECHNICAL					SIZE(mm)				QTY IN CONTAINER			REMARKS
Model	Wp	Vmp	Imp	Voc	Isc	Length	Width	Thickness	Weight(kg)	20’	40’	40HQ	REMARKS
GH005-M08	5	16.8	0.30	21.0	0.33	306	218	30	1.0				Cutting cell or Completed cell
GH010-M08	10	16.8	0.60	21.0	0.66	337	289	30	1.5	5186	10736	12550
GH020-M08	20	16.8	1.19	21.0	0.32	636	283	30	2.2	2824	5846	6834
GH040-M08	40	17.2	2.33	21.6	2.64	618	539	30	4.3	1626	3366	3934	Cutting cell or Completed cell
GH050-M08	50	17.2	2.9	21.6	3.30	767	539	35	4.8	1490	3084	3608
GH060-M08	60	17.2	3.49	21.6	3.96	732	658	35	3.4	1174	2430	2842
GH080-M08	80	17.2	4.65	21.6	5.28	1196	534	35	8.0	860	1780	2082	36pcs 5” cell
GH100-M08	100	17.2	5.80	21.6	6.60	1200	680	35	13.0	466	964	1128	6” Cutting cell
GH120-M08	120	17.2	6.98	21.6	7.92	1416	680	35	13.0	466	964	1128	36pcs 5” cell
GH180-P06	180	28.6	6.29	36.2	7.10	1590	960	50	18				56pcs 6” cell
GH200-P06	200	28.6	6.98	36.2	7.90	1590	960	50	18				56pcs 6” cell
GH240-P06	240	34.4	6.98	43.4	7.90	1880	960	50	22				72pcs 6” cell
GH280-M05	280	36.1	7.78	44.1	8.80	1880	960	50	22				72pcs 6” cell cell
