Specifications
1)Solar Panel kit2)with controllers,wires,clips,bracket
3)Two or Three folding solar panel
4)Folding Solar panel 225W
Solar Module PV Panel Monocrystalline or Polycrystalline Detils:
solar panel,solar module,mono-crystalline solar panel,poly-crystalline solar panel,mono-crystalline solar module,poly-crystalline solar module,PV system,solar panel kit
MODEL WP(W) ARRANGEMENT MODEL SIZE(L*W*H) Vmp(V) Imp(A) Voc(V) Isc(A)
GH028 255W 125*125M 8*12PCS 1580*1060*45MM 48.60 5.25 59.10 5.51
GH027 240W 125*125M 8*12PCS 1580*1060*45MM 48.00 5.01 59.00 5.40
GH026 230W 125*125M 8*12PCS 1580*1060*45MM 48.00 5.00 58.60 5.35
GH025 220W 125*125M 8*12PCS 1580*1060*45MM 47.50 4.65 58.00 5.25
GH024 195W 125*125M 6*12PCS 1580*808*40MM 37.20 5.25 44.20 5.52
GH023 190W 125*125M 6*12PCS 1580*808*40MM 37.00 5.15 44.20 5.45
GH022 185W 125*125M 6*12PCS 1580*808*40MM 36.60 5.10 43.20 5.40
GH021 180W 125*125M 6*12PCS 1580*808*40MM 36.60 5.00 43.20 5.35
GH020 175W 125*125M 6*12PCS 1580*808*40MM 36.20 4.85 43.20 5.25
GH019 170W 125*125M 6*12PCS 1580*808*40MM 36.60 4.75 43.00 5.10
GH012 95W 125*125M 4*9PCS 1200*550*35MM 18.00 5.27 22.60 5.55
GH011 90W 125*125M 4*9PCS 1200*550*35MM 18.00 5.10 21.60 5.45
GH010 85W 125*125M 4*9PCS 1200*550*35MM 17.20 5.00 22.60 5.35
GH009 80W 125*125M 4*9PCS 1200*550*35MM 17.20 4.80 21.60 5.25
GH008 75W 125*125M 4*9PCS 1200*550*35MM 17.20 4.41 21.60 5.10
GH007 70W 125*125M 4*9PCS 1200*550*35MM 16.80 4.20 21.60 4.90
MODEL WP(W) ARRANGEMENT MODEL SIZE(L*W*H) Vmp(V) Imp(A) Voc(V) Isc(A)
GH034 280W 156*156P/M 6*12PCS 1956*992*50MM 37.20 7.55 45.20 8.44
GH033 260W 156*156P/M 6*12PCS 1956*992*50MM 36.60 7.14 44.10 8.10
GH032 240W 156*156P/M 6*10PCS 1650*992*50MM 31.00 7.75 37.20 8.54
GH031 220W 156*156P/M 6*10PCS 1650*992*50MM 30.60 7.25 36.60 8.31
GH030 200W 156*156P/M 6*9PCS 1476*992*45MM 28.00 7.24 33.20 8.14
GH029 180W 156*156P/M 6*8PCS 1650*836*50MM 24.80 7.26 30.75 8.15
GH018 150W 156*156P/M 4*9PCS 1476*680*35MM 18.00 8.35 22.20 8.85
GH017 140W 156*156P/M 4*9PCS 1476*680*35MM 18.00 7.80 22.20 8.67
GH016 130W 156*156P/M 4*9PCS 1476*680*35MM 17.20 7.56 22.20 8.50
GH015 120W 156*156P/M 4*9PCS 1476*680*35MM 17.20 7.05 21.60 8.40
GH014 110W 156*120P/M 4*9PCS 1150*680*35MM 17.20 6.40 21.60 7.20
GH013 140W 156*120P/M 4*9PCS 1150*680*35MM 17.20 5.90 21.60 7.00
