Best gps tracker tk103 online gps gprs tracking system
Brief introduction:
This tracker TK103 is a new product based on the GSM / GPRS network and GPS satellite positioning system, which
set multiple functions of security, positioning, monitoring surveillance, emergency alarms and tracking in its entirety.
It can track and monitor remote target by SMS or internet.
| Specifications : | |
| Items | Specification |
| Work voltage | DC 9V to 36V |
| Operation Temp. | -20°C to +70°C |
| Storage Temp. | -40°C to +85°C |
| Relative Humidity | 5% to 90% |
| Indicator LED | Two colors indicator: Red(GSM), Green(GPS) |
| Host dimensions | 85*66*27mm |
| Host weight | 120g |
| Backup battery | 800Mah |
| GSM Module | SIMCOM |
| GPS Module | U-blox |
| GPS sensitivity | Acquisition sensitivity-148dbm, receiving sensitivity -159dbm |
| Frequency | GSM/GPRS 850/900/1800/1900MHz |
| GPS performance | Receive Channels:50channels;cold start:32S;warm start:32S |
| Hot start:1S;GPS sensitivity:-160dbm;GPS accuracy:<10m | |
| I/O | Input : ACC , SOS , Output : stop engine output ; |
Feature:
1.Tracking:Tracking in real time ,speed and mileage statistics,Geo-fencen setup etc.
GPRS location tracking via time interval .
3.Control remotely:Stop engine remotely via platform or sms
4.SMS setting:you could use SMS to setup gps devices ,or use usb cable to configure them direclty
without sending sms .
5.Cut power line alarm:thermostability backup battery ,will be triggered while the power line is removed
6.Dual mode positioning:When GPS signal is poor ,the device will switch to base station location
alarm :Over-speed alarm; SOS ; Main power on/off alarm ; ACC on/off alarm; geofence alarm ,
movement alarm etc.
7.Authorized wiretapping (Voice Monitoring):The vehicle can be wiretapped as authorized(inside microphone);
SMS set authorized TEL number; Platform send command to listen
8.APP Tracking:Support to track the cars/Motorcycle via android / IOS mobile phone
9.USB CABLE usage:connect with PC USB,setup parameter like apn ip port etc ;upgrade firmware
GPS Tracker TK103 Show Case:
GPS Tracker TK103 Real-time tracking paltform:
