Description
PT124B-123T is 4-20mA output pressure sensor for extruder with thermocouple , this series Melt Pressure transmitter (Flexible stem) ,with thermocouple can measure the pressure and temperature in one point. this melt pressure transmitter is widely used in both domestic and abroad.es The melt pressure transmitter can be utilized together with the N Series Intelligent Digital Pressure Instrument. Zero & full span can be adjustable, PT124G-123T welding with amplify circuit can be change to PT124B-123T , the standard signal be connected with PLC directly , all our melt pressure transmitter with advantages of high precision and reliable pressure measuring and good quality and internal 80% calibration. international standard , high accuracy , and can replace Dynisco ,Gefran ,GP50 absolutely .
Feature
Stainless steel welding , Easy to install
Zero and span adjustable
Various amplified signals optional
Internal 80% shunt calibration , high accuracy
Good stability and anti-jamming capability
Excellent stability and repeatability
standard output ,can replace Dynisco ,Gefran ,GP50 absolutely .
can measure the pressure and temperature in one point
Application
Chemical fiber Equipment
Plastic and Rubber manufacturing equipment
Medicine & Food process equipment
Measurement and Control all kinds of melt fluid
Specifications
Name |
4-20mA output pressure sensor for extruder with thermocouple |
Model |
PT124B-123T |
Pressure range |
0-3.5MPa…0-150MPa (0-500psi…20000psi) |
Over Pressure |
1.5 X FSO |
Combined Error |
± 0.5% FSO; ±0.25% FSO (Including Linearity, Repeatability & Hysteresis) |
Output |
4-20mA , 0-5V , 0-10V |
Input Voltage |
24VDC |
Repeatability |
+/- 0.2%FSO |
Bridge Resistance Input |
345 Ohms minimum |
Bridge Resistance Output |
350 Ohms +/- 10% |
Internal Shunt Calibration (R-Cal) |
80% FSO +/- 1% |
Insulation Resistance |
200 megohms @ 100 Vdc |
Max Diaphragm Temperature |
400°C |
Mounting Torque |
500 inch/lbs. max. |
Standard Wetted Parts |
Diaphragm coated 15-5 PH SST |
Electrical connector |
6PIN connector |
Thermocouple |
J,K,E,PT100 |
Process connector |
1/2″-20UNF, M14×1.5, M18×1.5 Optional |
Dimension
Order Guide : with "* "are required , with "---"is optional
Model |
Range |
output |
Rigid & flexible length (inch) |
Screw Thread |
Thermocouple |
Electric connector |
Accuracy |
others |
PT124B-123T |
* |
* |
* |
* |
* |
* |
* |
--- |
Example:PT124B-123T-500Bar-4-20mA -6/18”-1/2-20UNF-J-5PIN-0.5% | ||||||||
this rigid & flexible melt pressure transmitter with thermocouple to replace TPT4624 can mating with our N series to local display the pressure and temperature at the same time .
Our products are widely used in the field of hydraulic pressure, air pressure, petrochemical industry, automotive, air condition and compressor, construction machinery, plastic extrusion, chemical fiber, plastic rubber machine, non-woven fabrics and etc.
ZHYQ has a strong R&D team with more than 10 staffs, there are 3 senior engineers, 5 intermediate engineers, in the major of mechatronics. They have successfully developed a lot of new and High-tech products, won a number of patents and awards.
