PT124B-218 series high temperature pressure transmitter with cooling fan adopts imported thermo stability sensing element, make the transmitter work stability under 150℃. And it welds with cool lasing technology, there are cooling ribs between the pressure sensor chips and amplifier electrical circuit, it avoids the heat conduction efficiently.
Application
This item is suitable for measuring and controlling the pressure of moderate and high temperature (up to 150℃) fluid and steam.
Features
Various industrial standard signal output
Various electrical connector available
Certain stock for shortening delivery time
High accuracy, free of calibration
compact dimension design
Specification
Model | PT124B-218 high temperature pressure transmitter with cooling fan |
Pressure range | -1~0~1bar; 0~1~2000bar |
Over load | 150%FS |
Burst pressure | 300%FS |
Output | 4-20mA, 1-5V/0-5V, 0-10V |
Power supply | 12~36VDC |
Response time | <5ms |
Combine error | 0.25%FS; 0.5% FSO (Including Linearity, Repeatability & Hysteresis) |
Repeatability | ≤ +/- 0.2%FSO |
Long term stability | ≤ +/-0.2%FS/year |
Pressure connection | M20×1.5, G1/2,G1/4, 1/2NPT ( customer tailor ) |
Operating temperature | -20 ℃ ~ 150 ℃ |
Temperature compensation | 0℃ ~ 60℃ |
Electrical connector | Bendix connector,Hirschman DIN4365 and Gland lead |
Dimensions
Ordering guide * are required, --- is optional
Model | Range (bar) | Output | Screw Thread | Electric connection | Accuracy | Diameter (mm) | Other requirement |
PT124B-218 | * | * | * | * | * | * | --- |
Example: PT124B-218-80Bar-4/20mA-G1/2 | |||||||
ZHYQ has a strong R&D team with more than 10 staffs, there are 3 senior engineers, 5 intermediate engineers, in the major of mechatronics. They have successfully developed a lot of new and High-tech products, won a number of patents and awards.
