Help CenterAlloy Steel S Type Load Cell With Overload Protection
Related Products
-
Hot Selling High Quality Parallel Beam Load CellNegotiableMOQ: 10 Pieces -
Alloy Steel Structure Bridge Style Load Cell With Good QualityNegotiableMOQ: 10 Pieces
-
Spoke Style Load Cell Sensor With Outstanding Corrosion and Explosion ResistanceNegotiableMOQ: 10 Pieces
-
Alloy Steel Structure Bridge Style Load CellNegotiableMOQ: 10 Pieces
-
Column Style Load CellNegotiableMOQ: 10 Pieces
Specifications
S type load cell1.high precision and reliability
2.overload protection
3.alloy steel
4.high quality
Alloy steel S type load cell with overload protection
Description
1,material:alloy steel
2,S type
3,cost effective
4,high capacity
5,high precision
6,overload protection
7,for use in tension and compression
Application
Suitable for hanging scales, hopper scales, tension or compression applications.
Parameters
Rated Load(t) |
0.1~0.75, 1~20 |
||
Precision |
C2 |
Insulation Resistance(MΩ) |
≥5000(100VDC) |
Comprehensive Error(%F.S) |
0.03 |
Excitation Voltage(V) |
10(DC) |
Rated output(mv/v) |
2.0±0.02 |
Compensated temp.Range(°C ) |
-10~+40 |
Non-linearity(%F.S) |
0.03 |
Use Temp. Range(°C ) |
-20~+55 |
Hysteresis(%F.S) |
0.03 |
Temp.Effect on Zero(%F.S/10°C) |
0.03 |
Repeatability(%F.S) |
0.01 |
Temp.Effect on Span(%F.S/10°C) |
0.02 |
Creep(%F.S/30min) |
0.02 |
Safe Overload (%F.S) |
150 |
Zero Balance(%F.S) |
±1 |
Ultimate Overload(%F.S) |
200 |
Input Resistance(Ω) |
350±3 |
Defend Grade |
IP67/IP68 |
Output Resistance(Ω ) |
350±10 |
Cable(4PIN) |
RWP4*12/0.15*3M |
CZL-304
Rated Load(kg) |
500, 750, 1000 |
||
Precision |
C2 |
Insulation Resistance(MΩ) |
≥5000(100VDC) |
Comprehensive Error(%F.S) |
0.03 |
Excitation Voltage(V) |
9~12(DC) |
Rated output(mv/v) |
2.0±0.02 |
Compensated temp.Range(°C ) |
-10~+40 |
Non-linearity(%F.S) |
0.03 |
Use Temp.Range(°C ) |
-35~+65 |
Hysteresis(%F.S) |
0.03 |
Temp.Effect on Zero(%F.S/10°C) |
0.03 |
Repeatability(%F.S) |
0.01 |
Temp.Effect on Span(%F.S/10°C) |
0.03 |
Creep(%F.S/30min) |
0.02 |
Safe Overload (%F.S) |
120 |
Zero Balance(%F.S) |
±1.0 |
Ultimate Overload(%F.S) |
150 |
Input Resistance(Ω) |
350±3 |
Defend Grade |
IP67/TP68 |
Output Resistance(Ω ) |
350±3 |
Cable(4PIN) |
3m |
CZL-306
Dimensions
CZL-304
CZL-306
