ANGE is a professional manufacturer producing pp melt blown/spun filter making machine. We have independent research department to design and we excel at making new products according to clients’ special requirement.
Our clients are full of the world: India, Iran, Egypt, Taiwan, Ukraine, Turkey, Pakistan, and Thailand…
·Technical Support:
Mr. Xia- with 20 years’ experience in machine design and especially good in plastic extruding industry
Mr. Wen- with 15 years’ experience in filter making factory and can make all the filters you want
Mr. Chao- with 30 year's experience in designing PP string wound filter cartridge making machines
·PP Melt Blown Filter Cartridge Machine (UAC-1):
1 PP melt blown filter cartridge (UAC-1) production line includes:
1 Extruder; 1 Mold; 1 Atuo feeder; 1 Air Heater;
1 Air Compressor with power; 1 Air Tank;
1 Receiving Machine&Auto Center; 1 Small Controller;
1 Cleaning Machine for cleaning the mold.
AS WELL AS
1 Grooving Machine: make grooves on surface of PP cartridge (10" length of PP cartridge)
1 Carving Machine: make dots or keyholes on surface of PP cartridge
1 Dryer Blower: make orange peel on surface of PP cartridge
Performance Parameters of the 1 Extruder Machine(UAC-1)
| Name | PP melt blown filter cartridge |
| Mode | UAC-1 |
| Total Installed Power | 30KW |
| Actual Running Power | 15~20KW |
| Output |
80~105pcs/hour 2000~2500pcs/day |
| Raw Material | 100% New Polypropylene |
| Internal Diameter | 28mm default (free to customize) |
| Outer Diameter | 38~120mm (free to customize) |
| Length | 5",10",20",30",...(free to customize) |
| Filter Precision | 1μm,3μm,5μm,8μm,10μm,13μm,15μm |
| Surface of Filter |
Smooth Surface (extra tool) Orange Peel Surface (extra tool) Micro-grooving Surface(extra tool) Groove Surface (groving machine) Dotted Surface (extra tool) Logo on Surface (carving machine) |
| Default Voltage |
3 Phase 380V or; 1 Phase 220V If you need other voltage, extra $500 shall be charged. |
| Machine Weight |
Before Packing: 3~3.3T After Packing: 4T |
·Spare Parts For Free:
| Heating loop inside of extruders | 8pcs | Sensor | 5sets |
| Heating pipe inside of air heater | 2pcs | Bearing | 2pcs |
| Temperature controller | 3pcs | Blade | 20pcs |
| Button | 2 each | Heating Gun | 1 set |
| Porcelain bead and line | some | Solid-state relay | 2pcs |
|
Water-oil separator for screw compressor |
1 set |
Machine-oil filter for screw compressor |
1 set |
| Air filter for screw compressor | 1 set | Insulated Pipe | 2pcs |
| Needles | 40pcs | Insulated asbestos | some |
| Filter Screen/Net | 1 set |
·After-sales Service:
We provide 1 year warranty;
and our engineers will be available to overseas.
**We will also provide unlimited long-term technical guide by email or skype.
For Training:
**We suggest customers study at our factory firstly, and then our engineer goes to your factory if you still demand.
