Changzhou Helpass Low resistance tester inductor dc resistance tester
♦ Good stability
♦ Easy operation, display intuitive
♦ Zero adjustment, calibration convenient
♦ Set the comparison limit value conveniently
♦ Qualified and unqualified signal output and beep
♦ Display the sorting result
♦ Comprehensive communication interface
♦ Various of switch contact resistance
♦ Enameled resistance,Small diameter coil resistance
♦ Contact resistance
♦ Relay line package and contact resistance
♦ Transformer, inductor, motor, deflection coil winding resistance
♦ Weld contact resistance
♦ Conductor resistance
Specification:
Model |
HPS2511 |
||
Features | |||
Displayer |
HD LED digital tube display |
||
Display Digits |
5Digits |
||
Measurement Function | |||
Basic Accuracy |
0.1% |
||
Measurement Range |
10Ω -20kΩ |
||
Test Current |
100/10/1mA/100/10/1µA |
||
|
Measurement Speed(time/sec) |
Slow:5 Fast:10 |
||
Correction |
Full range short correction |
||
Measurement Terminal |
Four-wire system(2 detection terminals,2 drive terminals),five terminals |
||
Display Method |
Direct reading,ABS,%,Sorting Results |
||
Sorting and interfaces | |||
Sorting Function |
Onlap,Downlap,Qualified sorting, Beep( OFF,IN,HI,LO) |
||
General Specification | |||
Working Environment |
0°C -40°C ,≤90%RH |
||
Power Requirement |
198V -242V(AC),47.5Hz -63Hz |
||
Power Consumption |
≤15 V |
||
♦ AC power cord
♦ User's manual
♦ Testing report
♦ Warranty card and certificate
♦ Communication Cable
Technical Service:
♦We have professional engineers who design the test methods and test fixture for the product,debugged test equipment parameter to reach the optimal performance.
♦ We provide free technical training and offer free equipment maintenance technology.
♦ We can design special test programs and test fixture according to the customer.
