LED Display transformer/inductor short circuit dc resistance tester
♦ Ideal instrument for production test line
♦ Easy operation, display intuitive
♦ Good stability
♦ Zero adjustment, calibration convenient
♦ Set the comparison limit value conveniently
♦ Qualified and unqualified signal output and beep
♦ Display the sorting result
♦ Comprehensive communication interface
♦ Various of switch contact resistance
♦ Enameled resistance,Small diameter coil resistance
♦ Contact resistance
♦ Relay line package and contact resistance
♦ Transformer, inductor, motor, deflection coil winding resistance
♦ Weld contact resistance
♦ Conductor resistance
Model |
HPS2515 |
|
Features | ||
Displayer |
0.8 inch HD LED |
|
Measurement Function | ||
Accuracy |
0.1% |
|
Measurement Range |
0.1mΩ -2000Ω |
|
Resolution |
100µΩ |
|
Test Current |
100/10/1mA/100µA |
|
Speed(time/sec) |
20 |
|
Temperature Compensation |
Compensation range:0-80°C,Accuracy:0.2°C(option) |
|
General Specification | ||
Working Environment |
0°C -40°C ,≤90%RH |
|
Power Requirement |
198V -242V(AC),47.5Hz -63Hz |
|
Power Consumption |
≤15VA |
|
♦ AC power cord
♦ User's manual
♦ Testing report
♦ Warranty card and certificate
♦ HPS25002 Gold plated Kelvin clamp test line
♦ Communication Cable
Technical Service:
♦ We have professional engineers who design the test methods and test fixture for the product, debugged test equipment parameter to reach the optimal performance.
♦ We provide free technical training and offer free equipment maintenance technology.
♦ We can design special test programs and test fixture according to the customer.
We will arrange to ship your order with 3-15 working days after payment confirmed
1.Fedex/DHL/UPS:Reach most countries takes about 3-5 days
2.EMS:Reach most countries takes about 6-8 days
