2000 Lbs Heavy Duty Electric Winch

2000 Lbs Heavy Duty Electric Winch thumbnail-1
2000 Lbs Heavy Duty Electric Winch photo-1
US$ 130 - 180 MOQ: 50 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
weknown
Model Number:
P2000-1C
Contact Supplier Request Quote Chat Now
Shanghai Weknown Auto Parts Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name weknown
Model Number P2000-1C
Power Source Electric
Application Auto
Capacity 2000Ibs





2000 lbs Heavy Duty Electric Winch



P2000-1C(12V/24V)
2000lbs Electric Winch
Wireless Remote Control
Specification:
 Rated line pull  2000 lbs (907 kgs) single line
 Motor  Permanent magnet, 0.7kw/0.9hp 12v;0.8kw/1.0hp(24v)
 Gear reduction ratio  153:1
 Cable (Dia x L)  Φ5/32"*49'(Φ4mm*15m)
 Drum size (Dia x L)  Φ1.24"*2.88"(Φ31.5mm*73mm)
 Overall dimensions(L X W X H)  11.2"*4.1"*4.1"(285mm*105mm*105mm)
 Mounting bolt pattern  3.13"(79.5mm)
 Packing size  48*34*34cm 4PCS/CTN
 Weight  N.W/G.W: 20kg/22kg

Notice:
1) Do not use winch as a hoist, do not use for transportaion of people.
2) Don't operate and spool under full load over one minute continuously.
3) While motor is overtheating, please stop for a while to cool down.
4) Limited warranty.
Pull,speed,Amperes,Volts(First Layer)
Line pull
lbs(kgs)		 Line Speed
ft/min(m/min)		 Current
A

  12V DC    24V DC 12V DC    24V DC
0 10.5(3.2)  11.8(3.6) 12         6
500(227) 9.2(2.8)   10.2(3.1) 25        10
1000(454) 7.5(2.3)   8.5(2.6) 40        15
1500(680) 5.9(1.8)   6.9(2.1) 60        25
2000(907) 3.3(1.0)   3.6(1.1) 90        55

Line pull and Rope capacity In Layer
Layer Rated Line Pull
lbs(kgs)		 Total Rope on Drum
ft(mm)

1 2000(907) 6.5(2.0)
2 1630(739) 14.0(4.3)
3 1380(626) 22.0(6.8)
4 1190(540) 31.0(9.5)
5 1050(476) 41.0(12.5)
6 940(426) 49.0(15.0)
