Heavy Duty Electric Winch

Heavy Duty Electric Winch thumbnail-1
Heavy Duty Electric Winch photo-1
US$ 130 - 180 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
weknown
Model Number:
S95000
Contact Supplier Request Quote Chat Now
Shanghai Weknown Auto Parts Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name weknown
Model Number S95000
Power Source Electric
Application Auto
Capacity 9500LBS

Heavy Duty Electric Winch



S9500(12/24V) electric winch single
9500 lb Heavy Duty Electric Winch

SPECIFICATIONS
Rated Line Pull 9500LB (4300kgs) single line
Motor 5.5hp/4.0kw(12V) Series Wound
Control Remote switch, 12ft(3.7m)lead
Gear train 3 Stage Planetary
Gear train ratio 195.4:1
Clutch Sliding Ring Gear
Braking Action Two-way, Automatic In-The-Drum
Drum Size Φ2.5"*8.8"(Φ63.5mm*224mm)
Cable 5/16"of 94ft diameter(Φ8.3m*28m)
Fairlead 4-Way Roller Fairlead
Wireless Remote Control Optional
Battery Recommended:650CCA minimum for winching
Battery Leads 2 gauge,72"(183mm)
Finish Black powder coat
Overall Dimensions 21.1"×6.3"×8.6"(537mm×160mm×218mm)
Mounting Bolt Pattern 254mm×114.3mm
Weight N.W.81lb(37kg)    G.W.84lb(38kg)
Packing Size 57×19×34.5cm    1PC/CTN


9500LB LINE SPEED AND AMP DRAW (FIRST LAYER) 12V
Line Pull
lbs
 No LOAD
2000
4000
6000
 9500
kg
907
1814
2721
 4300
Line Speed
ft/min
 16.5 13.86 11.55 8.9 6.43
m/min
 5 4.2 3.5 2.7 1.95
Motor
Amps
 73 120 165 260 410


9500LB LINE PULL AND CABLE CAPACITY
Layers of cable 1 2 3 4
Rated line pull per layer lbs 9500 6600 5300 4500
kg 4300 2993 2404 2041
Cumulative cable capacity ft 18.5 41.2 68 92.4
m 5.6 12.5 20.6 28
