Rated Double-line Pulls...1500lbs(680KG)

Rated Double-line Pulls...1500lbs(680KG) photo-1
US$ 130 - 180 MOQ: 50 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
weknown
Model Number:
P750-1
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name weknown
Model Number P750-1
Power Source Electric
Application Auto
Capacity 3500Ibs





Rated double-line pulls...1500lbs(680KG)



P750-1(12V)
Rated double-line pulls...1500lbs(680KG)

Specification:
 Motor  0.3KW/0.4HP 12V, Permanent magnet
 Gear reduction ratio  153:1
 Drum Dimensions  Φ30mm*72mm
 Cable (Dia x L)  Φ3mm*15m
 Overall dimensions  275mm*105mm*105mm
 Mounting bolt pattern  Φ8.5mm*80m
 Packing size  33.5*32*36.5cm 4PCS/CTN
 Weight  N.W/G.W: 24kg/25kg


LINE SPEED AND AMP DRAW (FIRSRT LAYER) 12V
Line Pull lb NO 750 1250 1500
kg LOAD 340 567 680
Line Speed ft/min 5.28 4.6 3.3 2.47
m/min 1.6 1.4 1 0.75
Motor Amps 6 20 32 42


Line pull and cable capacity
Layers of cable 1 2 3 4 5
Rated line pull per layer Lb
Kg
1500 1197 1045 750 490
680 542 249 340 222
Cumulative ft 7.26 15.8 26 50 37
Cable capacity m 2.2 4.8 7.9 15 11.4

Notice:
1) Donot use winch as a hoist, do not use for transportation of people.
2) Don't operate and spool under full load over one minute continuously.
3) While motor is overheating, please stop for a while to cool down.
4) L imited warranty.
