4500 Lbs Electric Winch

4500 Lbs Electric Winch photo-1
US$ 130 - 180 MOQ: 50 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
weknown
Model Number:
P4500
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name weknown
Model Number P4500
Power Source Electric
Application Auto
Capacity 4500Ibs

Features:
1)Free spooling clutch.
2)Automatic braking action.
3)Specially designed differential planetary gearing for heavy duty.
4)Solenoid control box supplied.

 Specification:
 Rated line pull  4500 lbs (2041 kgs) single line
 Motor  Permanent magnet, 1.2kw/1.6hp(12V); 1.1kw/1.5hp(24V)
 Gear reduction ratio  159:1
 Cable (Dia×L)  φ1/4"×50'(φ6.3mm×15.2mm)
 Drum size (Dia×L)  φ1.8"×3"(φ45mm×76.2mm)
 Overall dimensions (L×W×H)  15.1"×7.2"×6.0"(383mm×183mm×152mm)
 Weight  N.W/G.W:18kg/19kg
 Packing size  44.5×30×22.5cm    1PC/CTN

Line speed and Amp draw
Line pull Lbs 0 1000 2000 3000 4000 4500
Kgs 0 454 907 1360 1815 2040
Line speed FPM 19.3 15 11 7.3 4.3 3.0
MPM 5.9 4.6 3.4 2.2 1.3 0.9
Amp draw Amps 28 85 145 220 290 350


Line pull and cable capacity
Layer of cable 1 2 3 4 5
Winch load Lbs 4500 4000 3000 2000 1000
Kg 2040 1815 1360 907 454

Notice:
1)Do not use winch as a hoist, do not use for transportation of people.
2)Don't operate and spool under full load over one minute continuously.
3)While motor is overheating, please stop for a while to cool down.
4)Limited warranty.
