API Subsurface Tubing Pump
US$ 450 - 850
MOQ: 10 Units
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
ZS
Theory:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
China main port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Oil-Drilling Seating Nipple EUE 8RD From ManufacturerUS$ 12 - 25MOQ: 100 Pieces -
API Standard Pump Seating Nipple EUE 8RD for Oilfield UseUS$ 12 - 25MOQ: 100 Pieces
-
API Standard Grade G105 Drill PipeUS$ 5 - 21MOQ: 10 Pieces
-
API Standard S135 Steel Drill PipeUS$ 5 - 21MOQ: 10 Pieces
-
API Standard Drill Pipe for SaleUS$ 5 - 21MOQ: 10 Pieces
Place of Origin
Henan, China
Brand Name
ZS
Theory
Other
Usage
Oil
Power
Hydraulic
Standard or Nonstandard
Standard
Pressure
High Pressure
Application
Other, extract oil
Work Principle:
In the uper stroke, the plunger is on the bottom of the tubing pump. Because the hydraulic pressure from the uper tubing, both up and traveling valves will close, When the plunger go up, the stationary valve open and oil will go through the pump, since the bottom pressure is higher than the uper pressure, then the fluid will be forced to go through the stationary valve and flow into the tubing.
In the down stroke,the traveling valve open and the presure drive the oil go into the plunger from the side hole of the extractor, then go into the tubing,
Feature:
The subsurface tubing pump is consist of tubing coupling, extension nipple, barrel coupling, barrel, traveling valve,plunger,extractor,staionary valve.
Technical Data:
| pump bore(mm) | barrel length(m) | plunger length(m) | tubing size(in) | ruker rod size(in) | pump cinstant(m3/d) |
| 28 | 3.3-9.5 | 0.6-6.9 | 2-7/8 | 3/4 | 0.877 |
| 32 | 3.3-9.5 | 0.6-6.9 | 2-7/8 | 3/4 | 1.140 |
| 38 | 3.3-9.5 | 0.6-6.9 | 2-7/8 | 3/4 | 1.642 |
| 44 | 3.3-9.5 | 0.6-6.9 | 2-7/8 | 3/4 | 2.235 |
| 50 | 3.3-8 | 0.6-5.4 | 2-7/8 | 3/4 | 3.012 |
| 56 | 3.3-8 | 0.6-5.4 | 2-7/8 | 3/4 | 3.694 |
| 70 | 3.3-8 | 0.6-5.4 | 3-1/2 | 7/8 | 5.518 |
| 95 | 3.3-9 | 0.6-1.8 | 4-1/2 | 1 | 9.128 |
