Help CenterUltrahigh Frequency Induction Heating Machine 10KW, 50-300KHz
Related Products
-
Ultrahigh Frequency Induction Heating Machine 6KW, 500-1100KHzUS$ 7,000 - 9,500MOQ: 1 Unit -
Ultrahigh Frequency Induction Heating Machine 6KW, 200-700KHzUS$ 5,000 - 7,500MOQ: 1 Unit
-
Ultrahigh Frequency Induction Heating Machine 6kwUS$ 5,000 - 7,500MOQ: 1 Unit
-
Ultrahigh Frequency Induction Heating Machine 3kwUS$ 5,000 - 7,500MOQ: 1 Unit
-
Ultrahigh Frequency Induction Heating Machine 100kwUS$ 17,000 - 22,000MOQ: 1 Set
Ultrahigh frequency (0.1-1.1MHZ)
General introduction of UF series:
The oscillating frequency of UF series machines is above 100KHZ, from 100KHZ to 1100KHZ, and machines
of this frequency are suitable for brazing, forging and heat treatment and a lot of other applications, especially
suitable for surface heat treatment and wire annealing and so on.
Power range of UF series is from 3KW to 160KW, UF series machines are of the most advanced technology,
and unique technology. Wide application for all metal heating areas.
Model explanation: UF-XXX AB
UF-- Ultrahigh frequency series
XXX – rated input power
AB – additional function A – with timer function B – split type that is with separated transformer
Main models and specifications:
Models |
Maximum input power |
Oscillating frequency |
Maximum input current |
Input voltage |
Duty cycle |
UF-04A |
4KW |
100-250KHZ |
15A |
Single phase 220V |
80% |
UF-03AB |
3KW |
0.5-1.1MHZ |
14A |
Single phase 220V |
80% |
UF-06A-I |
6.6KW |
200-500KHZ |
27A |
Single phase 220V |
80% |
UF-06A-II |
200-700KHZ |
||||
UF-06A-III |
0.5-1.1MHZ |
||||
UF-10A-I |
10KW |
50-300KHZ |
15A |
3phase 380V |
100% |
UF-10A-II |
10KW |
200-500KHZ |
15A |
Single phase 220V |
80% |
UF-20AB |
20KW |
50-250KHZ |
30A |
3phase 380V |
100% |
UF-30AB |
30KW |
50-200KHZ |
45A |
3phase 380V |
100% |
UF-40AB |
40KW |
50-200KHZ |
60A |
3phase 80V |
100% |
UF-60AB |
60KW |
30-150KHZ |
90A |
3phase 380V |
100% |
UF-100AB |
100KW |
30-150KHZ |
150A |
3phase 380V |
100% |
UF-160AB |
160KW |
30-120KHZ |
240A |
3phase 380V |
100% |
Send Inquiry to This Supplier
