Specifications
Mica fire resistant cable0.6/1kv
copper/pvc insulation and sheath
Low smoke low halogen
Mica fire resistant cable
Conductor: CU
Low smoke low halogen PVC insulated Low smoke low halogen PVC sheathed flame-retardancy power cable.
Certificate: ISO9001-2008; GB/T12706-2008;GB/T 17650-1 ~ 2-1998;
Application:
·Modern life safety systems, encompassing both fire detection and alarm system
·Building management systems
·Emergency lighting
·Public address
·Standby power supplies
·Computer installations
·Lifts and elevators
Their prolonged operation in a fire situation provides vital additional time to accomplish the evacuation of personnel, to contain and minimize the damage to equipment, plant and buildings, and to mount an effective fire fighting operation.
Construction:
Conductor : Class 2 annealed stranded plain copper
Fire Resisting Layer : Mica tape
Insulation : PVC
Assembly : The required number of cores may be laid up together with suitable fillers in round shape and suitable binder tape may be applied over the assembled cores.
Jacket: fire resistant PVC
Charcteristics:
Flame Retardancy
The difficulty of ignition and the ability of a cable to self-extinguish within a specified time period and distance from the point of application of a flame.
Flame Propagation
The property that determines the rate at which fire may develop and spread along a length of cable. Generally cables with reduced flame propagation also self-extinguish.
Acidic & Corrosive Gas Emission
The property that determines the propensity to corrosion of structures and equipment during or after a fire. Zero halogen cables significantly reduce the threat of corrosive and toxic gas emission, as they possess negligible levels of halogen.
Smoke Obscuration
The property that determines the time personnel have to evacuate an installation and mount an effective fire fighting operation. Low smoke cables have strictly controlled limits on the level of smoke emission under fire conditions.
Smoke Resistance (Circuit Integrity)
The maintenance of electrical circuit integrity for a prolonged period of time under fire conditions.
