Specifications
CU/XLPE/SWA/PVC electric cableRated voltage: 0.6/1kv
Insulation: PVC or XLPE
Jacket: PVC
CU/XLPE/SWA/PVC electric cable
1. Conductor: Copper
2. Armoured material: steel tape or steel wire
3. Standard: GB/T 12706-2008
4. Application: For laying down wells and under water, underground, able to bear certain axis pulling force and pressure.
5. Operation temperature: ≤90oC
7. Installation temperature: ≥0oC
8. Bending radius: A, Common bending radius:
a. ≥20D (1core)
b. ≥15D (3 cores)
D= outer diameter
B, Bending radius for the section which near the junction and connector:
a. ≥15D (1 core)
b. ≥12D (3,cores)
9. For the armouring of single-core cables, non-magnetic materials shall be adopted.
10. They can be made into flame retardant and fireproof type.
11. They can be made according to customers' requirements
