Help Center26/35kv Copper Core Xlpe Insulated Power Cable
Related Products
-
3c Copper Conductor XLPE Insulation Power CableUS$ 0.2 - 175MOQ: 1000 Meters -
8.7/15KV Medium Voltage Xlpe Insulated With Fire-resistant Power CableUS$ 1 - 200MOQ: 500 Meters
-
0.6/1kv 15/25kv 26/35kv Copper Core Xlpe Insulated Pvc Sheath Power CableUS$ 1 - 200MOQ: 500 Meters
-
XLPE Insulated Power Cable High Voltage CableUS$ 5 - 200MOQ: 500 Meters
-
Medium Voltage XLPE Power CableUS$ 1.4 - 175MOQ: 500 Meters
Specifications
this XLPE insulated electric cable is used in electric transmission and distribution system operating at rated 0.6/35kv .YJV32,42 : Cu conductor XLPE insulated steel wire armoured PVC sheathed electric cable .
YJLV32,42 : Al conductor XLPE insulated steel wire armoured PVC sheathed electric cable .
This style cable can use the voltage of 0.6/1,1.8/3 ,3.6/6 6/10 8.7/10 8.7/15 12/20 21/35 26/35KV .
26/35kv high voltage cable
Conductor: Copper
Insulation: XLPE or PVC
Standard: ISO 9001-2008;GB/T 12706-2008
26/35kv high voltage cable
1. Copper
2. XLPE insulated
3.Steel tape armoured
4. Rated voltage: 26/35KV
5. Application: For laying in doors, in treches and in ducsts for fixed installation with capability of screening.
The product is suitable for use in power transmission and distribution lines with rated high voltage power frequency.
6. Standard: According to GB/T12706-2008
7. XLPE insulated PVC sheathed power cable for medium voltage 8.7/15KV,
8. Conductor: Copper or aluminium
9. Section area: 25mm2---- 1200mm2
10. Core No.: one core, Three core
11. Insulation: XLPE or PVC
12. Sheath: PVC
13. Armour: Steel tape or steel wire
14. Working temperature: 90oC
15. Installation temperature: 0oC
16. Bending radius: A, Common bending radius:
A. 20D (1 and 2cores)
B. 15D (3 cores)
D= outer diameter
17. A single-core armoured cable is only applied to D.C transmission system. If it is required to use in A.S transimission system, no-magnetic material shhoud be applied as armoured tayer.
18. They can be made into flame retardant and fireproof type.
19. OEM is acceptable.
PICTURE'S SHOW ====>
