Help CenterMarine Antenna
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
G-ANTETECH
Model Number:
GA-GPS-05
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
China
Brand Name
G-ANTETECH
Model Number
GA-GPS-05
Specifications
Marine antennaProduct Description 1) Dieletric Antenna Center Frequency 1575.42MHz+-3 MHz V.S.W.R 1.5:1 Band Width +-5 MHz Impendence 50 ohm Peak Gain >3dBic Based on 7X7cm ground plane Gain Coverage >-4dBic at -90<0<+90(over 75% Volume) Polarization RHCP 2) LNA/Filter LNA Gain(Without cable) 28 dB/38 dB other Typical Noise Figure 1.5dB Filter Out Band Attenuation (f0=1575.42 MHZ) 7dB Min f0+/-20MHZ ; 20dB Min f0+/-50MHZ 30dB Min f0+/-100MHZ V.S.W.R <2.0 DC Voltage 2.7V/3.0V/3.3V/5.0V/ 3.0V to 5.0V /other DC Current 11mA/15mA Max 3) Mechanical Weight <430gram Size 93(diameter)X136mm Cable RG58 5 to 100 meters Connector SMA/SMB/SMC/BNC/FME/TNC/MCX /MMCX or other Mounting M24X1.5 Housing white 4) Environmental Working Temp -40'C~+85'C Storage Temp. -45'C~+100'C Vibration Sine sweep 1g(0-p)10~50~10Hz each axis Humidity Humidity95%~100%RH Weatherproof 100%Waterproof
