(Manufactory) 800-2100MHZ 3G Magnetic Antenna With CRC9 TS9
US$ 1 - 3
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
g-antetech
Model Number:
GA-GSM-06
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
g-antetech
Model Number
GA-GSM-06
Specifications
800-2100MHZ 3G Magnetic Antenna with CRC9 TS9Frequency Range 800-2100MHZ
Gain 3.5
Max Input powerW 60
Input Impedance 50
(Manufactory) 800-2100MHZ 3G Magnetic Antenna with CRC9 TS9
Item |
Specifications |
|
Antenna |
Frequency Range |
824~960/1710~2170MHz |
Polarization |
Linear |
|
Gain |
3.5dBi(Zenith) |
|
V.S.W.R |
<2.0 |
|
Impendance |
50Ω |
|
Dimension |
Φ30x90mm |
|
Mechanical |
Cable |
RG174 or others |
Connector |
SMA/SMB/SMC/MMCX/MCX/MC-Card/MS147/TS9/CRC9/Farkra |
|
Mounting Method |
Magnet |
|
Environmental |
Operating Temperature |
-40'C~+85'C |
Relative Humidity |
Up to 95% |
|
Ingress Protection |
IP67 |
|
Vibration |
10 to 55Hz with 1.5mm amplitude 2hours |
|
Environmentally Friendly |
ROHS Compliant |
|
Our factory also have many other kinds of 3G Antennas as followings,
