Wheelchair Lifts For Vehicle

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Other, wheelchair lift	Certification	CE
Size	1220*751 mm	Material	steel
Bus Model	HIGER	Place of Origin	Jiangsu, China
Brand Name	xinder	Model Number	WL-UVL-700, WL-UVL -700

Product Description

The WL- UVL Series Wheelchair Lift for bus offers an innovative solution to your mobility. With the lift mounted underneath the vehicle, it remains out of sight and out of your way until needed. This means easy access, a clear side view and maximum interior space.

The UVL Series lifts are electric in operation for both the in/out cycle and the outboard roll stop. The up/down cycle is hydraulic in operation. All functions are controlled by the standard hand-held control or the optional remote control.

The UVL Series is designed for installation at the side door of domestic full-size vans, buses and coaches. Installation of the UVL requires modification of the vehicle - consult your Dealer for details.

Advantages:

Super thin compact design
Electric outboard rollstop and automatic inboard rollstop
No-skid aluminum honeycomb platform
Powerful hydraulic pump ensures smooth, stable operation for heavy wheelchairs
Dual lifting arms are activated hydraulically, providing a stable and strong lifting environment.
Side handrails (Option), for increased comfort and security
Sound and flash light alarm during operation of platform
Built in manual backup system

Technical specification

Max lifting load 350 Kg
Max lifting height 700 -1400mm
Voltage 12 / 24 V
Length & width of platform 1220*751 mm

Model	WL-UVL-700	WL-UVL-700-S	WL-UVL-700(II)
Platform size	751*1220	751*1220	751*1220
Max. up stroke	505	505	430
Max. down stroke	500	500	540
Length required to install lift	1940	1812	1867
Height of lift rear end	133	133	133
Height of lift front end	167	167	167
Distance between guide frame and up fitting surface	53	53	53
Distance between front fitting surface and spindle of main arm	347	75	145
Installation position	for the bus with three steps; installed in step	for the bus with two steps; installed under chassis	for coach or tourist bus; installed in the luggage
