Help Center2k Ohms Potentiometer
Related Products
Specifications
1)2k ohms potentiometer2)Metal shaft
3)Panel mounting
4)Carbon seriflux from Japan
5)Best quality ,best price.
Potentiometer Expert since year 1967!
Company tenent: "What customer needs is our pursuit!"
Company aim: Pursue technology innovation, create green and intelligent life.
Full inspection:
1) This guarantee does not cover damage due to misuse, abuse, neglect of alteration .
Caution:
1.Use of chemicals:Synthetic resins such as polycarbonate are used in the potentiometer.therefore,care must be taken not expose the resistor to thick atmosphere of ammonia,amins ,alkali solution,aromatic hydrocarbon,ketenes,esters,halogeneous hydrocarbon,ketenes esters,halogeneous hydrocarbons,ets.
2.When soldering ,avoid using water-soluble flux,othrewise,itmight cause and adverse effect on molding material and metal.
3.Although electric poles of resistors are generally formed by silver printing,we provide carbon coating over the silver poles to enhance reliablility against ntact us if you wish to use the part in a low residual resistance state.
Product Type & Condition :
1. Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated . So,please consult the stock situation when you inquire.
Buyer Reading:
1. Please confirm receipt of products if the items you received , and if the goods was damaged please contact us immediately. send the photo to us that we can check and give you best solution .
2. We only guarantee Delivery in time but we couldn't control the express delivery time. Our related sales person will be responsible to send the AWB for the delivered goods in the next workday. you can check the AWB in the website which we send to you. For the AWB you also can call to the local branch of the express company in your company.
Item No.: RV24 2k ohms potentiometer
|
Rated power |
A:0.5W ( 50°C) |
| ing voltage | DC 315V |
| Resistance range & tolerance | 100Ω --2MΩ ±10% |
| Resistance tape | A. B . C. |
| End resistance | ≤ 3 Ω |
| Rotational noise | ≤ 47mV |
| potentiometers | can be making spacer ,screw |
| Rotation torque | 5-30mN.m |
| Total mechanical travel | 300°±5° |
| Mechanical life | 15000cycles |
| potentiometers | can be making knob |
| Brand name | rocket |
|
Each carton contains two inner boxes. Each inner box has 500 pots. total of 25 slots on each layer. 25*2=50pcs each layers.50 pcs for one layer*10 layer=500pcs (10 layer for each box), total in each inner box is 500pcs.Grand total per box is 1000 pcs.
Size:55cm*45cm*45cm
Weight:2000pcs 40KG.1000pcs 20KG
