Home > Electrical & Electronics > Passive Components > Resistor & Potentiometer > Potentiometer 5k

Potentiometer 5k

Name: Potentiometer 5k
Brand: Rocket
SKU: 130155345

US$ 0.01 - 1 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Rocket

Model Number:

RV24

Contact Supplier Request Quote Chat Now

Ningbo Huayu Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Rocket

Model Number RV24

Type Rotary Potentiometer

Technology Carbon Composition

Resistance 100Ω----2MΩ

Resistance Tolerance ±10%

Rated Power 0.5W

Max. Operating Voltage DC 500V

Operating Temperature 75°C

Specifications

1)potentiometer 5k
2)Metal shaft
3)Panel mounting
4)Carbon seriflux from Japan
5)Potentionmeters expert.

Company Information

Our Services

Potentiometer Expert since year 1967!

Company tenent: "What customer needs is our pursuit!"
Company aim: Pursue technology innovation, create green and intelligent life.

Full inspection:

1)98% percent of pass .

2)It is understood that 2% discrepancy rate in quantity and major quality is acceptable for the buyers.

Warranty Terms: CONDITION APPLY

1) The pump is guaranteed to be free for a period of 1 year from the date of purchase .”Discoloration and rust “

2)Mechanical life 10000 laps, non-artificial damage.

Note: Warranty will not be provided in case of the following circumstances.
1) This guarantee does not cover damage due to misuse, abuse, neglect of alteration .

2) Out of range of application .(more than 10000 mechanical life.)

3) This guarantee does not cover damage due to incorrect wiring or abnormal power supply .

FAQ

Caution:

1.Use of chemicals:Synthetic resins such as polycarbonate are used in the potentiometer.therefore,care must be taken not expose the resistor to thick atmosphere of ammonia,amins ,alkali solution,aromatic hydrocarbon,ketenes,esters,halogeneous hydrocarbon,ketenes esters,halogeneous hydrocarbons,ets.

2.When soldering ,avoid using water-soluble flux,othrewise,itmight cause and adverse effect on molding material and metal.

3.Although electric poles of resistors are generally formed by silver printing,we provide carbon coating over the silver poles to enhance reliablility against ntact us if you wish to use the part in a low residual resistance state.

Product Type & Condition :

1. Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated . So,please consult the stock situation when you inquire.

Buyer Reading:

1. Please confirm receipt of products if the items you received , and if the goods was damaged please contact us immediately. send the photo to us that we can check and give you best solution .

2. We only guarantee Delivery in time but we couldn't control the express delivery time. Our related sales person will be responsible to send the AWB for the delivered goods in the next workday. you can check the AWB in the website which we send to you. For the AWB you also can call to the local branch of the express company in your company.

Product Description

Item No.: RV24 potentiometer 5k

Feature

1)Flux builded-up prevention is taken through inserting molding around the resistor with resin.

2)A large variety of products lined up to support various applications.

3)Miniature design for Audio applications.

4)Long life type available

Electrical characteristics

Total rotation angle :260°

Operating force :20-200gf.cm

Shaft stop strength :3kgf.cm/min

Switch working angle/stroke: 30 ±10°

Switch working torque /force:50-300gf.cm

Rated dissipation:0.125w 0.06w

Rated voltage :200V 150V

Insulation resistance :DC500V 500M Ω

Voltage proof:AC500V,1minute

Switch contact resistance:less than 20m Ω

Switch ratings:12VDC 1A

Mechanical endurance :10000cycles

Switch life:10000times

Resistance taper:A /B/ C

Rated power	A:0.5W ( 50°C)
ing voltage	DC 315V
Resistance range & tolerance	100Ω --2MΩ ±10%
Resistance tape	A. B . C.
End resistance	≤ 3 Ω
Rotational noise	≤ 47mV
potentiometers	can be making spacer ,screw
Rotation torque	5-30mN.m
Total mechanical travel	300°±5°
Mechanical life	15000cycles

potentiometers	can be making knob
Brand name	rocket

Packaging & Shipping

Each carton contains two inner boxes. Each inner box has 500 pots. total of 25 slots on each layer. 25*2=50pcs each layers.50 pcs for one layer*10 layer=500pcs (10 layer for each box), total in each inner box is 500pcs.Grand total per box is 1000 pcs.

Size:55cm*45cm*45cm

Weight:2000pcs 40KG.1000pcs 20KG
