Top Quality 90KW HF induction heating generator for steel plate forging
Features of induction heating generator for steel plate forging
1. Light weight, small size and simple structure.
2. Simple to operate, a few minutes are enough for user to learn it.
3. Simple to install, installation can be done by unprofessional person very easily.
4. Heating fast: the fastest heating speed is less than one second, and heating speed can be adjusted.
5. Different shapes and sizes of induction coils can be changed easily to heat different parts.
6. Multi-display functions, with displays of over current, over voltage, water lack, phase lack and so on, machine can be protected from destroys and can be repaired easily.
7. Advantages: The machine is equipped with timer, so user can preset machine’s power, operating time, heating time and retaining time to realize a simple heating curve.
WZP-90 Induction heating machine:generator and transformer
Technical parameters of WZP-90 induction heating generator for steel plate forging
Model |
WZP-90 |
Work power |
3 phase 380V+/-10%, 50-60HZ |
Input voltage |
320V-420V can be changed, depend on your country's electric power |
Input current |
6-90A |
Input power |
3-45KW(power adjusted stepless) |
Oscillation frequency |
15-30 KHZ |
Cooling water pressure |
0.3 MPA |
|
Size of geneartor: Transformer |
generator 665*400*730mm ; transformer 660*490*435mm; |
Weight of generator ; transformer |
47kgs; 62kgs |
Water cooling protection point |
Below 50 degree celsius |
Applications of induction heating generator for steel plate forging
I. Heat Treatment Industry
1. Hardware tool hardening: such as vices, hammers, pilers, wrenches, etc.
2. Various of automobile and motorcycle accessory hardening.
3. High frequency hardening of hydraulic components: such as piston, rotators, switching shafts, gears, etc.
4. Various of gears and shaft of electric tools.
5. Various of woodworking tools, such as axes, planers, etc.
II. Welding Industry
1. Welding machining cutters, such as lathe tools, planer tools, milling tools, etc.
2. Welding various of diamond tools, such as diamond saw blades, diamond drilling tools, etc.
3. Welding various of coal miller picks and digger picks.
4. Welding various of mechanical cutters.
III. Forging Industry
1. Forging various of standard parts and non-standard parts.
2. Preheating hardware tools, such as pilers, wrenches, etc.
3. Forging drills, drill handles, drill bits, hardening gears.
4. Extruding stainless steel containers.
Pictures of induction heating generator
Other applications of induction heating generator
Wooden cases or carton, as you required. Good packages , is suitable for long distance transport,sea transport.
1. One year warranty;
2. Long-term technical support;
3. Replacing parts for free;
4. Overseas on-site technicians service if required.
Thanks for your time and we are looking forward to your cooperation.We will provide you the best produce with professional service!Feel free to send us and inquiries!
Sincerely provide service for you !
