High speed automatic feeding electric horizontal forging machine
Features of horizontal forging machine
1.Save electronic: can save 30% electric than election tubes.can save 20% electric than KGPS.
2.Use Simens IGBT module for induction heating forge furnace
3.Work stable: safe protection, safe operation
4.Forging speed fast: no oxidation layer, small deformation
5.Small size: Light weight, easy installation
6.Environmental protection: no pollution, no noise and dust
7.Wide heating parts range: can heat all kinds of parts
8.Equipment can install time relay to control heating time and temperature control.
9.OEM service supplied for horizontal forging machine.
Composition of horizontal forging machine
1.Medium frequency heating power supply
2.Induction forging furnace
Technical specification of horizontal forging machine
Model |
Rated power |
Rated frequency (KHZ) |
Temperature°C |
Power consumption (KWH/T) |
Work piece diameter (MM) |
GTR-50 |
50KW |
10 |
900-1250 |
350-450 |
4-30 |
GTR-100 |
100KW |
8-10 |
900-1250 |
350-450 |
19-41 |
GTR-150 |
150KW |
6-8 |
900-1250 |
350-450 |
19-41 |
GTR-200 |
200KW |
6-8 |
900-1250 |
350-450 |
24-51 |
GTR-250 |
250KW |
6-8 |
900-1250 |
350-450 |
24-51 |
GTR-300 |
300KW |
2-4 |
900-1250 |
350-450 |
29-61 |
GTR-350 |
350KW |
2-4 |
900-1250 |
350-450 |
29-61 |
GTR-400 |
400KW |
2-4 |
900-1250 |
350-450 |
29-81 |
GTR-500 |
500KW |
2-4 |
900-1250 |
350-450 |
39-81 |
GTR-600 |
600KW |
1-2 |
900-1250 |
350-450 |
49-101 |
GTR-750 |
750KW |
1-2 |
900-1250 |
350-450 |
49-101 |
GTR-1000 |
1000KW |
0.5-1 |
900-1250 |
350-450 |
59-121 |
Pictures of horizontal forging machine
This is tailor-made,according to work piece size .
1. Reply your inquiry within 24 working hours
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price ,compare with the same industry
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need
9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10.If you need, will arrange one engineer to your place,instruct install machine and training operators.
11.Excess warranty period(12 months warranty), you can buy the spare parts from us with special discount price.
12.Provide long-terms technical support.
What’s your MOQ? |
Any quantity of machine will be accepted. MOQ:1 Set |
Which place your factory is located? |
We are located in Shenqiu County, Zhoukou city, Henan Province ,China |
How far from Beijing? I think it is more closer to Shanghai |
Our factory is near both and Shanghai. We have office in Zhengzhou, we can pick up you at Zhengzhou CGO airport,and then to our factory via expressway about two hours. |
We need to see some more videos for production line and also pictures of your factory, water drawing and panel drawing |
Well, we have many videos show our customer’s machine working scene(Various of applications: forging,hardening, brazing, shrink fitting, melting and hot coating etc. According to your work piece processing requirements,) send you the corresponding video link or send by email. 2. Yes, we can provide you factory pictures and machine water connection and control panel details. |
Do you have quality certifications? |
Yes, we got the ISO9001:2000 International quality management system certification in August,2001, |
How do you packing the machines? |
Standard export wooden cases(plywood) Usually every set machine will be used two wooden cases: one for packing induction heating generator, one for packing transformer. Inside will be filled with plastic foam for waterproof and shockproof |
More questions….? |
Updating… |
More information about horizontal forging machine,please feel free to contact us !
