QC11Y-6*3200 CNC hydraulic guillotine shear machine
Properties and characters:
1.It is the second generation of hydraulic plate shearing machine.
2.Machine frame and knife rest are welded integral. Vibration eliminates stress. Precision is kept well.
3.The advanced integrated hydraulic system is reliable.
4.Adopt three-point support rolling guide to eliminate gas between supports and improve shearing quality.
5.Gap between blades is adjusted with hand-operated wheels, so it is quick, exact and convenient.
6.The four rectangular blades all can be used for a long time.
7.The up knife rest adopts interior inclining structure for falling conveniently and improving precision.
8.It has the function of shearing by stages.
9.It has the lighting function.
10.Back stop is controlled with E21 numerical control system.
Convenient working and person security protection(Optional):
1. The machine can be equipped with full closed back side door to prevent any careless inside when cutting.
2. The machine can be equipped with cutted lift out declined platform under the back gauge for convenient operation.
3. Light curtain can be equipped also for security standard needs.
4. Light function is equipped for convenient checking and care when cutting.
NC/CNC System and advance touch screen function :
The normal system for CNC are Nanjing ESTUN (Holand Delem 60% JOINTED) system: ESTUN E20,ESTUN E21s and ESTUN E200 system,DELEM DA310 and DELEM DA360 and also Swiss CYBELEC system DNC60 and CT6 (Touch Screen). X/Y axis can be controlled and displayed. The backgauge distance can be controlled and calculated into 1000MM long.
The NC system will be ESTUN E21 mostly we use for high quality guarantee.
All of their instruction manual is available when applied to SIECC/SIECCTECH
Technical data:
No. | value | unit | remark | ||||
1 | Max cutting thickness | 6 | mm | σb≤450N/mm | |||
2 | Max cutting width | 3200 | mm | ||||
3 | Throat depth | 100 | mm | ||||
4 | Shearing angle | 0.5-1.5 | ° | ||||
5 | Strokes time | 16-45 | Min-1 | ||||
6 | Max stroke volume of up knife | 100 | mm | ||||
7 | Max shearing force | 140 | KN | ||||
8 | Max compressive force feeding | KN | Change with the load | ||||
9 | Max working force of system | 12 | MPa | ||||
10 | Adjustment of back gauge | 10-600 | mm | ||||
11 | Oil pump | model | 25MCY14-1B | ||||
flow | 32 | ml/r | |||||
12 | Master motor | model | Y132M-4 | ||||
power | 7.5 | kW | |||||
Rota e speed | 1440 | r/min | |||||
13 | dimension | length | 3730 | mm | |||
width | 2075 | mm | No including the former ruler | ||||
height | 1970 | mm | |||||
Standard exporting package for shearing machine: |
1. inner machine, it is packaged in moistureproof film. |
2. pallet or wood box. |
3. ground fixed bolt to confirm steady and avoid destory. |
4. tightly exporting standard belf to fasten machine in container. |
|
Hudong shearing machine ocean shipping: |
1. Tell me the nearest port, Hudong give you the best shipping cost. |
Hudong provide operational manuals and videos for CNC shearing machine. |
• Warmly welcome customers to the factory, Hudong free training. |
• Our guarantee time is 2 years from B/L date. If any component is damaged during guarantee time. we can send the component to thecustomer by DHL, TNT freely. |
• Hudong provide 24 hours on-line service by MSN, Skype, Email and Telephone. |
Hudong company provides oriented after-sales service including the oversea engineers trainning available and also international dealer center for any emergency guidance. We have established worldwide network to guarantee our timely response for your any demand no matter where are you.
We welcome engineers from your side to learn the technical design and normal maintenance here, this will help your easy in understanding and helpful if you need to be our dealer.
However, don’t worry ,we have our company own CD/Manual to show you along with the machine. So you can learn this from the existing documents to deepen your knowledge and understanding.
Anyhow there are another way is through internet video face to face for machine teaching, because of the high development in internet ,the world has become smaller and you can easy cath us if any assistance needed.
Through all the ways , we will guarantee the service quality and ensure you will be well helped anytime anywhere.
1. We have a R&D team who have average35 years experience in designing and producing stage lighting, we can OEM different kinds of products according to your requirement, in order to produce the products more suitable to your market !
2. We have a lot of customers from overseas as well as domestic. A lot of our customers has established long term business relationship with us.
3. All the products have 1 year warranty. All products are conducted strick QC and inspection before shipping.
1. If you have any problem or suggestion about our products or service, you can contact me or our sales manager whenever you want. We will give you a satisfied reply.
We can ensure you the proper level of sales in the region, stability and timeless of payment terms.
